Sentiment Analysis on Encrypted Data with Homomorphic Encryption

Introduction

Homomorphic encryption is a type of encryption that allows for computation on encrypted data without needing to decrypt it first. This makes it well-suited for applications where user's personal and potentially sensitive data is at risk, such as sentiment analysis of private messages.

In this blog post, we will provide a practical tutorial on how to use the Concrete-ML library to build a sentiment analysis model on encrypted data. We will cover the following topics:

Setting up the environment
Using a public dataset
Text representation using a transformer
Classifying with XGBoost
Predicting over encrypted data
Deployment

Setup the Environment

To get started, make sure your pip and setuptools are up to date by running:

pip install -U pip setuptools

Now we can install all the required libraries for this blog with the following command:

pip install concrete-ml transformers datasets

Using a Public Dataset

The dataset we use in this notebook can be found here. To represent the text for sentiment analysis, we chose to use a transformer hidden representation as it yields high accuracy for the final model in a very efficient way.

Here is the code to load the dataset and visualize some statistics:

from datasets import load_dataset
train = load_dataset("osanseviero/twitter-airline-sentiment")["train"].to_pandas()
text_X = train['text']
y = train['airline_sentiment']
y = y.replace(['negative', 'neutral', 'positive'], [0, 1, 2])
pos_ratio = y.value_counts()[2] / y.value_counts().sum()
neg_ratio = y.value_counts()[0] / y.value_counts().sum()
neutral_ratio = y.value_counts()[1] / y.value_counts().sum()
print(f'Proportion of positive examples: {round(pos_ratio * 100, 2)}%')
print(f'Proportion of negative examples: {round(neg_ratio * 100, 2)}%')
print(f'Proportion of neutral examples: {round(neutral_ratio * 100, 2)}%')

The output is as follows:

Proportion of positive examples: 16.14% Proportion of negative examples: 62.69% Proportion of neutral examples: 21.17%

Text Representation using a Transformer

Transformers are neural networks often trained to predict the next words to appear in a text (this task is commonly called self-supervised learning). They can also be fine-tuned on some specific subtasks such that they specialize and get better results on a given problem.

Here is the code to use a transformer to represent the text:

import torch
from transformers import AutoModelForSequenceClassification, AutoTokenizer
device = "cuda:0" if torch.cuda.is_available() else "cpu"
# Load the tokenizer (converts text to tokens)
tokenizer = AutoTokenizer.from_pretrained("cardiffnlp/twitter-roberta-base-sentiment-latest")

# Load the pre-trained model
transformer_model = AutoModelForSequenceClassification.from_pretrained(
   "cardiffnlp/twitter-roberta-base-sentiment-latest"
)

# Function that transforms a list of texts to their representation
# learned by the transformer.
def text_to_tensor(
   list_text_X_train: list,
   transformer_model: AutoModelForSequenceClassification,
   tokenizer: AutoTokenizer,
   device: str,
) -> np.ndarray:
   # Tokenize each text in the list one by one
   tokenized_text_X_train_split = []
   tokenized_text_X_train_split = [
       tokenizer.encode(text_x_train, return_tensors="pt")
       for text_x_train in list_text_X_train
   ]

   # Send the model to the device
   transformer_model = transformer_model.to(device)
   output_hidden_states_list = [None] * len(tokenized_text_X_train_split)

   for i, tokenized_x in enumerate(tqdm.tqdm(tokenized_text_X_train_split)):
       # Pass the tokens through the transformer model and get the hidden states
       # Only keep the last hidden layer state for now
       output_hidden_states = transformer_model(tokenized_x.to(device), output_hidden_states=True)[
           1
       ][-1]
       # Average over the tokens axis to get a representation at the text level.
       output_hidden_states = output_hidden_states.mean(dim=1)
       output_hidden_states = output_hidden_states.detach().cpu().numpy()
       output_hidden_states_list[i] = output_hidden_states

   return np.concatenate(output_hidden_states_list, axis=0)

# Let's vectorize the text using the transformer
list_text_X_train = text_X_train.tolist()
list_text_X_test = text_X_test.tolist()

X_train_transformer = text_to_tensor(list_text_X_train, transformer_model, tokenizer, device)
X_test_transformer = text_to_tensor(list_text_X_test, transformer_model, tokenizer, device)

Classifying with XGBoost

Now that we have our training and test sets properly built to train a classifier, next comes the training of our FHE model. Here it will be very straightforward, using a hyper-parameter tuning tool such as GridSearch from scikit-learn.

Here is the code to train the model:

from concrete.ml.sklearn import XGBClassifier
from sklearn.model_selection import GridSearchCV
# Let's build our model
model = XGBClassifier()

# A gridsearch to find the best parameters
parameters = {
    "n_bits": [2, 3],
    "max_depth": [1],
    "n_estimators": [10, 30, 50],
    "n_jobs": [-1],
}

# Now we have a representation for each tweet, we can train a model on these.
grid_search = GridSearchCV(model, parameters, cv=5, n_jobs=1, scoring="accuracy")
grid_search.fit(X_train_transformer, y_train)

# Check the accuracy of the best model
print(f"Best score: {grid_search.best_score_}")

# Check best hyperparameters
print(f"Best parameters: {grid_search.best_params_}")

# Extract best model
best_model = grid_search.best_estimator_

The output is as follows:

Best score: 0.8378111718275654 Best parameters: {'max_depth': 1, 'n_bits': 3, 'n_estimators': 50, 'n_jobs': -1}

Predicting over Encrypted Data

Now let's predict over encrypted text. The idea here is that we will encrypt the representation given by the transformer rather than the raw text itself. In Concrete-ML, you can do this very quickly by setting the parameter execute_in_fhe=True in the predict function. This is just a developer feature (mainly used to check the running time of the FHE model).

Here is the code to predict over encrypted data:

import time
# Compile the model to get the FHE inference engine
# (this may take a few minutes depending on the selected model)
start = time.perf_counter()
best_model.compile(X_train_transformer)
end = time.perf_counter()
print(f"Compilation time: {end - start:.4f} seconds")

# Let's write a custom example and predict in FHE
tested_tweet = ["AirFrance is awesome, almost as much as Zama!"]
X_tested_tweet = text_to_tensor(tested_tweet, transformer_model, tokenizer, device)
clear_proba = best_model.predict_proba(X_tested_tweet)

# Now let's predict with FHE over a single tweet and print the time it takes
start = time.perf_counter()
decrypted_proba = best_model.predict_proba(X_tested_tweet, execute_in_fhe=True)
end = time.perf_counter()
fhe_exec_time = end - start
print(f"FHE inference time: {fhe_exec_time:.4f} seconds")

# Check that the FHE predictions are the same as the clear predictions
print(f"Probabilities from the FHE inference: {decrypted_proba}")
print(f"Probabilities from the clear model: {clear_proba}")

The output is as follows:

Compilation time: 9.3354 seconds FHE inference time: 4.4085 seconds

Deployment

At this point, our model is fully trained and compiled, ready to be deployed. In Concrete-ML, you can use a deployment API to do this easily.

Here is the code to deploy the model:

# Let's save the model to be pushed to a server later
from concrete.ml.deployment import FHEModelDev
fhe_api = FHEModelDev("sentiment_fhe_model", best_model)
fhe_api.save()

Conclusion

We have presented a way to leverage the power of transformers where the representation is then used to:

Train a machine learning model to classify tweets, and
Predict over encrypted data using this model with FHE.

The final model (Transformer representation + XGBoost) has a final accuracy of 85%, which is above the transformer itself with 80% accuracy (please see this notebook for the comparisons).

The FHE execution time per example is 4.4 seconds on a 16 cores cpu.

The files for deployment are used for a sentiment analysis app that allows a client to request sentiment analysis predictions from a server while keeping its data encrypted all along the chain of communication.

Concrete-ML (Don't forget to star us on Github ⭐️💛) allows straightforward ML model building and conversion to the FHE equivalent to be able to predict over encrypted data.
