π RuView

See through walls with WiFi. No cameras. No wearables. No Internet. Just radio waves.

WiFi DensePose turns commodity WiFi signals into real-time human pose estimation, vital sign monitoring, and presence detection — all without a single pixel of video.

By analyzing Channel State Information (CSI) disturbances caused by human movement, the system reconstructs body position, breathing rate, and heartbeat using physics-based signal processing and machine learning.

Edge modules are small programs that run directly on the ESP32 sensor — no internet needed, no cloud fees, instant response.

What How Speed

Pose estimation CSI subcarrier amplitude/phase → DensePose UV maps 54K fps (Rust)

Breathing detection Bandpass 0.1-0.5 Hz → FFT peak 6-30 BPM

Heart rate Bandpass 0.8-2.0 Hz → FFT peak 40-120 BPM

Presence sensing RSSI variance + motion band power < 1ms latency

Through-wall Fresnel zone geometry + multipath modeling Up to 5m depth

30 seconds to live sensing — no toolchain required

docker pull ruvnet/wifi-densepose:latest docker run -p 3000:3000 ruvnet/wifi-densepose:latest

Open http://localhost:3000

Note

CSI-capable hardware required. Pose estimation, vital signs, and through-wall sensing rely on Channel State Information (CSI) — per-subcarrier amplitude and phase data that standard consumer WiFi does not expose. You need CSI-capable hardware (ESP32-S3 or a research NIC) for full functionality. Consumer WiFi laptops can only provide RSSI-based presence detection, which is significantly less capable.

Hardware options for live CSI capture:

Option Hardware Cost Full CSI Capabilities

ESP32 Mesh (recommended) 3-6x ESP32-S3 + WiFi router ~$54 Yes Pose, breathing, heartbeat, motion, presence

Research NIC Intel 5300 / Atheros AR9580 ~$50-100 Yes Full CSI with 3x3 MIMO

Any WiFi Windows, macOS, or Linux laptop $0 No RSSI-only: coarse presence and motion

No hardware? Verify the signal processing pipeline with the deterministic reference signal: python v1/data/proof/verify.py

📖 Documentation

Document Description

User Guide Step-by-step guide: installation, first run, API usage, hardware setup, training

Build Guide Building from source (Rust and Python)

Architecture Decisions 44 ADRs — why each technical choice was made, organized by domain (hardware, signal processing, ML, platform, infrastructure)

Domain Models 7 DDD models (RuvSense, Signal Processing, Training Pipeline, Hardware Platform, Sensing Server, WiFi-Mat, CHCI) — bounded contexts, aggregates, domain events, and ubiquitous language

Real-time pose skeleton from WiFi CSI signals — no cameras, no wearables

The server is optional for visualization and aggregation — the ESP32 runs independently for presence detection, vital signs, and fall alerts.

🚀 Key Features

Sensing

See people, breathing, and heartbeats through walls — using only WiFi signals already in the room.

Feature What It Means

🔒 Privacy-First Tracks human pose using only WiFi signals — no cameras, no video, no images stored

💓 Vital Signs Detects breathing rate (6-30 breaths/min) and heart rate (40-120 bpm) without any wearable

👥 Multi-Person Tracks multiple people simultaneously, each with independent pose and vitals — no hard software limit (physics: ~3-5 per AP with 56 subcarriers, more with multi-AP)

🧱 Through-Wall WiFi passes through walls, furniture, and debris — works where cameras cannot

🚑 Disaster Response Detects trapped survivors through rubble and classifies injury severity (START triage)

📡 Multistatic Mesh 4-6 low-cost sensor nodes work together, combining 12+ overlapping signal paths for full 360-degree room coverage with sub-inch accuracy and no person mix-ups (ADR-029)

🌐 Persistent Field Model The system learns the RF signature of each room — then subtracts the room to isolate human motion, detect drift over days, predict intent before movement starts, and flag spoofing attempts (ADR-030)

Intelligence

The system learns on its own and gets smarter over time — no hand-tuning, no labeled data required.

Feature What It Means

🧠 Self-Learning Teaches itself from raw WiFi data — no labeled training sets, no cameras needed to bootstrap (ADR-024)

🎯 AI Signal Processing Attention networks, graph algorithms, and smart compression replace hand-tuned thresholds — adapts to each room automatically (RuVector)

🌍 Works Everywhere Train once, deploy in any room — adversarial domain generalization strips environment bias so models transfer across rooms, buildings, and hardware (ADR-027)

👁️ Cross-Viewpoint Fusion AI combines what each sensor sees from its own angle — fills in blind spots and depth ambiguity that no single viewpoint can resolve on its own (ADR-031)

🔮 Signal-Line Protocol A 6-stage processing pipeline transforms raw WiFi signals into structured body representations — from signal cleanup through graph-based spatial reasoning to final pose output (ADR-033)

🔒 QUIC Mesh Security All sensor-to-sensor communication is encrypted end-to-end with tamper detection, replay protection, and seamless reconnection if a node moves or drops offline (ADR-032)

Performance & Deployment

Fast enough for real-time use, small enough for edge devices, simple enough for one-command setup.

Feature What It Means

⚡ Real-Time Analyzes WiFi signals in under 100 microseconds per frame — fast enough for live monitoring

🦀 810x Faster Complete Rust rewrite: 54,000 frames/sec pipeline, multi-arch Docker image, 1,031+ tests

🐳 One-Command Setup docker pull ruvnet/wifi-densepose:latest — live sensing in 30 seconds, no toolchain needed (amd64 + arm64 / Apple Silicon)

📡 Fully Local Runs completely on a $9 ESP32 — no internet connection, no cloud account, no recurring fees. Detects presence, vital signs, and falls on-device with instant response

📦 Portable Models Trained models package into a single .rvf file — runs on edge, cloud, or browser (WASM)

🔬 How It Works

WiFi routers flood every room with radio waves. When a person moves — or even breathes — those waves scatter differently. WiFi DensePose reads that scattering pattern and reconstructs what happened:

WiFi Router → radio waves pass through room → hit human body → scatter ↓ ESP32 mesh (4-6 nodes) captures CSI on channels 1/6/11 via TDM protocol ↓ Multi-Band Fusion: 3 channels × 56 subcarriers = 168 virtual subcarriers per link ↓ Multistatic Fusion: N×(N-1) links → attention-weighted cross-viewpoint embedding ↓ Coherence Gate: accept/reject measurements → stable for days without tuning ↓ Signal Processing: Hampel, SpotFi, Fresnel, BVP, spectrogram → clean features ↓ AI Backbone (RuVector): attention, graph algorithms, compression, field model ↓ Signal-Line Protocol (CRV): 6-stage gestalt → sensory → topology → coherence → search → model ↓ Neural Network: processed signals → 17 body keypoints + vital signs + room model ↓ Output: real-time pose, breathing, heart rate, room fingerprint, drift alerts

No training cameras required — the Self-Learning system (ADR-024) bootstraps from raw WiFi data alone. MERIDIAN (ADR-027) ensures the model works in any room, not just the one it trained in.

🏢 Use Cases & Applications

WiFi sensing works anywhere WiFi exists. No new hardware in most cases — just software on existing access points or a $8 ESP32 add-on. Because there are no cameras, deployments avoid privacy regulations (GDPR video, HIPAA imaging) by design.

Scaling: Each AP distinguishes ~3-5 people (56 subcarriers). Multi-AP multiplies linearly — a 4-AP retail mesh covers ~15-20 occupants. No hard software limit; the practical ceiling is signal physics.

Why WiFi sensing wins Traditional alternative

🔒 No video, no GDPR/HIPAA imaging rules Cameras require consent, signage, data retention policies

🧱 Works through walls, shelving, debris Cameras need line-of-sight per room

🌙 Works in total darkness Cameras need IR or visible light

💰 $0-$8 per zone (existing WiFi or ESP32) Camera systems: $200-$2,000 per zone

🔌 WiFi already deployed everywhere PIR/radar sensors require new wiring per room

🏥 Everyday — Healthcare, retail, office, hospitality (commodity WiFi)

Use Case What It Does Hardware Key Metric Edge Module

Elderly care / assisted living Fall detection, nighttime activity monitoring, breathing rate during sleep — no wearable compliance needed 1 ESP32-S3 per room ($8) Fall alert <2s Sleep Apnea, Gait Analysis

Hospital patient monitoring Continuous breathing + heart rate for non-critical beds without wired sensors; nurse alert on anomaly 1-2 APs per ward Breathing: 6-30 BPM Respiratory Distress, Cardiac Arrhythmia

Emergency room triage Automated occupancy count + wait-time estimation; detect patient distress (abnormal breathing) in waiting areas Existing hospital WiFi Occupancy accuracy >95% Queue Length, Panic Motion

Retail occupancy & flow Real-time foot traffic, dwell time by zone, queue length — no cameras, no opt-in, GDPR-friendly Existing store WiFi + 1 ESP32 Dwell resolution ~1m Customer Flow, Dwell Heatmap

Office space utilization Which desks/rooms are actually occupied, meeting room no-shows, HVAC optimization based on real presence Existing enterprise WiFi Presence latency <1s Meeting Room, HVAC Presence

Hotel & hospitality Room occupancy without door sensors, minibar/bathroom usage patterns, energy savings on empty rooms Existing hotel WiFi 15-30% HVAC savings Energy Audit, Lighting Zones

Restaurants & food service Table turnover tracking, kitchen staff presence, restroom occupancy displays — no cameras in dining areas Existing WiFi Queue wait ±30s Table Turnover, Queue Length

Parking garages Pedestrian presence in stairwells and elevators where cameras have blind spots; security alert if someone lingers Existing WiFi Through-concrete walls Loitering, Elevator Count

🏟️ Specialized — Events, fitness, education, civic (CSI-capable hardware)

Use Case What It Does Hardware Key Metric Edge Module

Smart home automation Room-level presence triggers (lights, HVAC, music) that work through walls — no dead zones, no motion-sensor timeouts 2-3 ESP32-S3 nodes ($24) Through-wall range ~5m HVAC Presence, Lighting Zones

Fitness & sports Rep counting, posture correction, breathing cadence during exercise — no wearable, no camera in locker rooms 3+ ESP32-S3 mesh Pose: 17 keypoints Breathing Sync, Gait Analysis

Childcare & schools Naptime breathing monitoring, playground headcount, restricted-area alerts — privacy-safe for minors 2-4 ESP32-S3 per zone Breathing: ±1 BPM Sleep Apnea, Perimeter Breach

Event venues & concerts Crowd density mapping, crush-risk detection via breathing compression, emergency evacuation flow tracking Multi-AP mesh (4-8 APs) Density per m² Customer Flow, Panic Motion

Stadiums & arenas Section-level occupancy for dynamic pricing, concession staffing, emergency egress flow modeling Enterprise AP grid 15-20 per AP mesh Dwell Heatmap, Queue Length

Houses of worship Attendance counting without facial recognition — privacy-sensitive congregations, multi-room campus tracking Existing WiFi Zone-level accuracy Elevator Count, Energy Audit

Warehouse & logistics Worker safety zones, forklift proximity alerts, occupancy in hazardous areas — works through shelving and pallets Industrial AP mesh Alert latency <500ms Forklift Proximity, Confined Space

Civic infrastructure Public restroom occupancy (no cameras possible), subway platform crowding, shelter headcount during emergencies Municipal WiFi + ESP32 Real-time headcount Customer Flow, Loitering

Museums & galleries Visitor flow heatmaps, exhibit dwell time, crowd bottleneck alerts — no cameras near artwork (flash/theft risk) Existing WiFi Zone dwell ±5s Dwell Heatmap, Shelf Engagement

🤖 Robotics & Industrial — Autonomous systems, manufacturing, android spatial awareness WiFi sensing gives robots and autonomous systems a spatial awareness layer that works where LIDAR and cameras fail — through dust, smoke, fog, and around corners. The CSI signal field acts as a "sixth sense" for detecting humans in the environment without requiring line-of-sight.

Use Case What It Does Hardware Key Metric Edge Module

Cobot safety zones Detect human presence near collaborative robots — auto-slow or stop before contact, even behind obstructions 2-3 ESP32-S3 per cell Presence latency <100ms Forklift Proximity, Perimeter Breach

Warehouse AMR navigation Autonomous mobile robots sense humans around blind corners, through shelving racks — no LIDAR occlusion ESP32 mesh along aisles Through-shelf detection Forklift Proximity, Loitering

Android / humanoid spatial awareness Ambient human pose sensing for social robots — detect gestures, approach direction, and personal space without cameras always on Onboard ESP32-S3 module 17-keypoint pose Gesture Language, Emotion Detection

Manufacturing line monitoring Worker presence at each station, ergonomic posture alerts, headcount for shift compliance — works through equipment Industrial AP per zone Pose + breathing Confined Space, Gait Analysis

Construction site safety Exclusion zone enforcement around heavy machinery, fall detection from scaffolding, personnel headcount Ruggedized ESP32 mesh Alert <2s, through-dust Panic Motion, Structural Vibration

Agricultural robotics Detect farm workers near autonomous harvesters in dusty/foggy field conditions where cameras are unreliable Weatherproof ESP32 nodes Range ~10m open field Forklift Proximity, Rain Detection

Drone landing zones Verify landing area is clear of humans — WiFi sensing works in rain, dust, and low light where downward cameras fail Ground ESP32 nodes Presence: >95% accuracy Perimeter Breach, Tailgating

Clean room monitoring Personnel tracking without cameras (particle contamination risk from camera fans) — gown compliance via pose Existing cleanroom WiFi No particulate emission Clean Room, Livestock Monitor

🔥 Extreme — Through-wall, disaster, defense, underground These scenarios exploit WiFi's ability to penetrate solid materials — concrete, rubble, earth — where no optical or infrared sensor can reach. The WiFi-Mat disaster module (ADR-001) is specifically designed for this tier.

Use Case What It Does Hardware Key Metric Edge Module

Search & rescue (WiFi-Mat) Detect survivors through rubble/debris via breathing signature, START triage color classification, 3D localization Portable ESP32 mesh + laptop Through 30cm concrete Respiratory Distress, Seizure Detection

Firefighting Locate occupants through smoke and walls before entry; breathing detection confirms life signs remotely Portable mesh on truck Works in zero visibility Sleep Apnea, Panic Motion

Prison & secure facilities Cell occupancy verification, distress detection (abnormal vitals), perimeter sensing — no camera blind spots Dedicated AP infrastructure 24/7 vital signs Cardiac Arrhythmia, Loitering

Military / tactical Through-wall personnel detection, room clearing confirmation, hostage vital signs at standoff distance Directional WiFi + custom FW Range: 5m through wall Perimeter Breach, Weapon Detection

Border & perimeter security Detect human presence in tunnels, behind fences, in vehicles — passive sensing, no active illumination to reveal position Concealed ESP32 mesh Passive / covert Perimeter Breach, Tailgating

Mining & underground Worker presence in tunnels where GPS/cameras fail, breathing detection after collapse, headcount at safety points Ruggedized ESP32 mesh Through rock/earth Confined Space, Respiratory Distress

Maritime & naval Below-deck personnel tracking through steel bulkheads (limited range, requires tuning), man-overboard detection Ship WiFi + ESP32 Through 1-2 bulkheads Structural Vibration, Panic Motion

Wildlife research Non-invasive animal activity monitoring in enclosures or dens — no light pollution, no visual disturbance Weatherproof ESP32 nodes Zero light emission Livestock Monitor, Dream Stage

Edge Intelligence (ADR-041)

Small programs that run directly on the ESP32 sensor — no internet needed, no cloud fees, instant response. Each module is a tiny WASM file (5-30 KB) that you upload to the device over-the-air. It reads WiFi signal data and makes decisions locally in under 10 ms. ADR-041 defines 60 modules across 13 categories — all 60 are implemented with 609 tests passing.

Category Examples

🏥 Medical & Health Sleep apnea detection, cardiac arrhythmia, gait analysis, seizure detection

🔐 Security & Safety Intrusion detection, perimeter breach, loitering, panic motion

🏢 Smart Building Zone occupancy, HVAC control, elevator counting, meeting room tracking

🛒 Retail & Hospitality Queue length, dwell heatmaps, customer flow, table turnover

🏭 Industrial Forklift proximity, confined space monitoring, structural vibration

🔮 Exotic & Research Sleep staging, emotion detection, sign language, breathing sync

📡 Signal Intelligence Cleans and sharpens raw WiFi signals — focuses on important regions, filters noise, fills in missing data, and tracks which person is which

🧠 Adaptive Learning The sensor learns new gestures and patterns on its own over time — no cloud needed, remembers what it learned even after updates

🗺️ Spatial Reasoning Figures out where people are in a room, which zones matter most, and tracks movement across areas using graph-based spatial logic

⏱️ Temporal Analysis Learns daily routines, detects when patterns break (someone didn't get up), and verifies safety rules are being followed over time

🛡️ AI Security Detects signal replay attacks, WiFi jamming, injection attempts, and flags abnormal behavior that could indicate tampering

⚛️ Quantum-Inspired Uses quantum-inspired math to map room-wide signal coherence and search for optimal sensor configurations

🤖 Autonomous & Exotic Self-managing sensor mesh — auto-heals dropped nodes, plans its own actions, and explores experimental signal representations

All implemented modules are no_std Rust, share a common utility library, and talk to the host through a 12-function API. Full documentation: Edge Modules Guide. See the complete implemented module list below.

🧩 Edge Intelligence — All 65 Modules Implemented (ADR-041 complete) All 60 modules are implemented, tested (609 tests passing), and ready to deploy. They compile to wasm32-unknown-unknown, run on ESP32-S3 via WASM3, and share a common utility library. Source: crates/wifi-densepose-wasm-edge/src/

Core modules (ADR-040 flagship + early implementations):

Module File What It Does

Gesture Classifier gesture.rs DTW template matching for hand gestures

Coherence Filter coherence.rs Phase coherence gating for signal quality

Adversarial Detector adversarial.rs Detects physically impossible signal patterns

Intrusion Detector intrusion.rs Human vs non-human motion classification

Occupancy Counter occupancy.rs Zone-level person counting

Vital Trend vital_trend.rs Long-term breathing and heart rate trending

RVF Parser rvf.rs RVF container format parsing

Vendor-integrated modules (24 modules, ADR-041 Category 7):

📡 Signal Intelligence — Real-time CSI analysis and feature extraction

Module File What It Does Budget

Flash Attention sig_flash_attention.rs Tiled attention over 8 subcarrier groups — finds spatial focus regions and entropy S (<5ms)

Coherence Gate sig_coherence_gate.rs Z-score phasor gating with hysteresis: Accept / PredictOnly / Reject / Recalibrate L (<2ms)

Temporal Compress sig_temporal_compress.rs 3-tier adaptive quantization (8-bit hot / 5-bit warm / 3-bit cold) L (<2ms)

Sparse Recovery sig_sparse_recovery.rs ISTA L1 reconstruction for dropped subcarriers H (<10ms)

Person Match sig_mincut_person_match.rs Hungarian-lite bipartite assignment for multi-person tracking S (<5ms)

Optimal Transport sig_optimal_transport.rs Sliced Wasserstein-1 distance with 4 projections L (<2ms)

🧠 Adaptive Learning — On-device learning without cloud connectivity

Module File What It Does Budget

DTW Gesture Learn lrn_dtw_gesture_learn.rs User-teachable gesture recognition — 3-rehearsal protocol, 16 templates S (<5ms)

Anomaly Attractor lrn_anomaly_attractor.rs 4D dynamical system attractor classification with Lyapunov exponents H (<10ms)

Meta Adapt lrn_meta_adapt.rs Hill-climbing self-optimization with safety rollback L (<2ms)

EWC Lifelong lrn_ewc_lifelong.rs Elastic Weight Consolidation — remembers past tasks while learning new ones S (<5ms)

🗺️ Spatial Reasoning — Location, proximity, and influence mapping

Module File What It Does Budget

PageRank Influence spt_pagerank_influence.rs 4x4 cross-correlation graph with power iteration PageRank L (<2ms)

Micro HNSW spt_micro_hnsw.rs 64-vector navigable small-world graph for nearest-neighbor search S (<5ms)

Spiking Tracker spt_spiking_tracker.rs 32 LIF neurons + 4 output zone neurons with STDP learning S (<5ms)

⏱️ Temporal Analysis — Activity patterns, logic verification, autonomous planning

Module File What It Does Budget

Pattern Sequence tmp_pattern_sequence.rs Activity routine detection and deviation alerts S (<5ms)

Temporal Logic Guard tmp_temporal_logic_guard.rs LTL formula verification on CSI event streams S (<5ms)

GOAP Autonomy tmp_goap_autonomy.rs Goal-Oriented Action Planning for autonomous module management S (<5ms)

🛡️ AI Security — Tamper detection and behavioral anomaly profiling

Module File What It Does Budget

Prompt Shield ais_prompt_shield.rs FNV-1a replay detection, injection detection (10x amplitude), jamming (SNR) L (<2ms)

Behavioral Profiler ais_behavioral_profiler.rs 6D behavioral profile with Mahalanobis anomaly scoring S (<5ms)

⚛️ Quantum-Inspired — Quantum computing metaphors applied to CSI analysis

Module File What It Does Budget

Quantum Coherence qnt_quantum_coherence.rs Bloch sphere mapping, Von Neumann entropy, decoherence detection S (<5ms)

Interference Search qnt_interference_search.rs 16 room-state hypotheses with Grover-inspired oracle + diffusion S (<5ms)

🤖 Autonomous Systems — Self-governing and self-healing behaviors

Module File What It Does Budget

Psycho-Symbolic aut_psycho_symbolic.rs 16-rule forward-chaining knowledge base with contradiction detection S (<5ms)

Self-Healing Mesh aut_self_healing_mesh.rs 8-node mesh with health tracking, degradation/recovery, coverage healing S (<5ms)

🔮 Exotic (Vendor) — Novel mathematical models for CSI interpretation

Module File What It Does Budget

Time Crystal exo_time_crystal.rs Autocorrelation subharmonic detection in 256-frame history S (<5ms)

Hyperbolic Space exo_hyperbolic_space.rs Poincare ball embedding with 32 reference locations, hyperbolic distance S (<5ms)

🏥 Medical & Health (Category 1) — Contactless health monitoring

Module File What It Does Budget

Sleep Apnea med_sleep_apnea.rs Detects breathing pauses during sleep S (<5ms)

Cardiac Arrhythmia med_cardiac_arrhythmia.rs Monitors heart rate for irregular rhythms S (<5ms)

Respiratory Distress med_respiratory_distress.rs Alerts on abnormal breathing patterns S (<5ms)

Gait Analysis med_gait_analysis.rs Tracks walking patterns and detects changes S (<5ms)

Seizure Detection med_seizure_detect.rs 6-state machine for tonic-clonic seizure recognition S (<5ms)

🔐 Security & Safety (Category 2) — Perimeter and threat detection

Module File What It Does Budget

Perimeter Breach sec_perimeter_breach.rs Detects boundary crossings with approach/departure S (<5ms)

Weapon Detection sec_weapon_detect.rs Metal anomaly detection via CSI amplitude shifts S (<5ms)

Tailgating sec_tailgating.rs Detects unauthorized follow-through at access points S (<5ms)

Loitering sec_loitering.rs Alerts when someone lingers too long in a zone S (<5ms)

Panic Motion sec_panic_motion.rs Detects fleeing, struggling, or panic movement S (<5ms)

🏢 Smart Building (Category 3) — Automation and energy efficiency

Module File What It Does Budget

HVAC Presence bld_hvac_presence.rs Occupancy-driven HVAC control with departure countdown S (<5ms)

Lighting Zones bld_lighting_zones.rs Auto-dim/off lighting based on zone activity S (<5ms)

Elevator Count bld_elevator_count.rs Counts people entering/leaving with overload warning S (<5ms)

Meeting Room bld_meeting_room.rs Tracks meeting lifecycle: start, headcount, end, availability S (<5ms)

Energy Audit bld_energy_audit.rs Tracks after-hours usage and room utilization rates S (<5ms)

🛒 Retail & Hospitality (Category 4) — Customer insights without cameras

Module File What It Does Budget

Queue Length ret_queue_length.rs Estimates queue size and wait times S (<5ms)

Dwell Heatmap ret_dwell_heatmap.rs Shows where people spend time (hot/cold zones) S (<5ms)

Customer Flow ret_customer_flow.rs Counts ins/outs and tracks net occupancy S (<5ms)

Table Turnover ret_table_turnover.rs Restaurant table lifecycle: seated, dining, vacated S (<5ms)

Shelf Engagement ret_shelf_engagement.rs Detects browsing, considering, and reaching for products S (<5ms)

🏭 Industrial & Specialized (Category 5) — Safety and compliance

Module File What It Does Budget

Forklift Proximity ind_forklift_proximity.rs Warns when people get too close to vehicles S (<5ms)

Confined Space ind_confined_space.rs OSHA-compliant worker monitoring with extraction alerts S (<5ms)

Clean Room ind_clean_room.rs Occupancy limits and turbulent motion detection S (<5ms)

Livestock Monitor ind_livestock_monitor.rs Animal presence, stillness, and escape alerts S (<5ms)

Structural Vibration ind_structural_vibration.rs Seismic events, mechanical resonance, structural drift S (<5ms)

🔮 Exotic & Research (Category 6) — Experimental sensing applications

Module File What It Does Budget

Dream Stage exo_dream_stage.rs Contactless sleep stage classification (wake/light/deep/REM) S (<5ms)

Emotion Detection exo_emotion_detect.rs Arousal, stress, and calm detection from micro-movements S (<5ms)

Gesture Language exo_gesture_language.rs Sign language letter recognition via WiFi S (<5ms)

Music Conductor exo_music_conductor.rs Tempo and dynamic tracking from conducting gestures S (<5ms)

Plant Growth exo_plant_growth.rs Monitors plant growth, circadian rhythms, wilt detection S (<5ms)

Ghost Hunter exo_ghost_hunter.rs Environmental anomaly classification (draft/insect/wind/unknown) S (<5ms)

Rain Detection exo_rain_detect.rs Detects rain onset, intensity, and cessation via signal scatter S (<5ms)

Breathing Sync exo_breathing_sync.rs Detects synchronized breathing between multiple people S (<5ms)

🧠 Self-Learning WiFi AI (ADR-024) — Adaptive recognition, self-optimization, and intelligent anomaly detection Every WiFi signal that passes through a room creates a unique fingerprint of that space. WiFi-DensePose already reads these fingerprints to track people, but until now it threw away the internal "understanding" after each reading. The Self-Learning WiFi AI captures and preserves that understanding as compact, reusable vectors — and continuously optimizes itself for each new environment.

What it does in plain terms:

Turns any WiFi signal into a 128-number "fingerprint" that uniquely describes what's happening in a room

Learns entirely on its own from raw WiFi data — no cameras, no labeling, no human supervision needed

Recognizes rooms, detects intruders, identifies people, and classifies activities using only WiFi

Runs on an $8 ESP32 chip (the entire model fits in 55 KB of memory)

Produces both body pose tracking AND environment fingerprints in a single computation

Key Capabilities

What How it works Why it matters

Self-supervised learning The model watches WiFi signals and teaches itself what "similar" and "different" look like, without any human-labeled data Deploy anywhere — just plug in a WiFi sensor and wait 10 minutes

Room identification Each room produces a distinct WiFi fingerprint pattern Know which room someone is in without GPS or beacons

Anomaly detection An unexpected person or event creates a fingerprint that doesn't match anything seen before Automatic intrusion and fall detection as a free byproduct

Person re-identification Each person disturbs WiFi in a slightly different way, creating a personal signature Track individuals across sessions without cameras

Environment adaptation MicroLoRA adapters (1,792 parameters per room) fine-tune the model for each new space Adapts to a new room with minimal data — 93% less than retraining from scratch

Memory preservation EWC++ regularization remembers what was learned during pretraining Switching to a new task doesn't erase prior knowledge

Hard-negative mining Training focuses on the most confusing examples to learn faster Better accuracy with the same amount of training data

Architecture

WiFi Signal [56 channels] → Transformer + Graph Neural Network ├→ 128-dim environment fingerprint (for search + identification) └→ 17-joint body pose (for human tracking)

Quick Start

Step 1: Learn from raw WiFi data (no labels needed)

cargo run -p wifi-densepose-sensing-server -- --pretrain --dataset data/csi/ --pretrain-epochs 50

Step 2: Fine-tune with pose labels for full capability

cargo run -p wifi-densepose-sensing-server -- --train --dataset data/mmfi/ --epochs 100 --save-rvf model.rvf

Step 3: Use the model — extract fingerprints from live WiFi

cargo run -p wifi-densepose-sensing-server -- --model model.rvf --embed

Step 4: Search — find similar environments or detect anomalies

cargo run -p wifi-densepose-sensing-server -- --model model.rvf --build-index env

Training Modes

Mode What you need What you get

Self-Supervised Just raw WiFi data A model that understands WiFi signal structure

Supervised WiFi data + body pose labels Full pose tracking + environment fingerprints

Cross-Modal WiFi data + camera footage Fingerprints aligned with visual understanding

Fingerprint Index Types

Index What it stores Real-world use

env_fingerprint Average room fingerprint "Is this the kitchen or the bedroom?"

activity_pattern Activity boundaries "Is someone cooking, sleeping, or exercising?"

temporal_baseline Normal conditions "Something unusual just happened in this room"

person_track Individual movement signatures "Person A just entered the living room"

Model Size

Component Parameters Memory (on ESP32)

Transformer backbone ~28,000 28 KB

Embedding projection head ~25,000 25 KB

Per-room MicroLoRA adapter ~1,800 2 KB

Total ~55,000 55 KB (of 520 KB available)

The self-learning system builds on the AI Backbone (RuVector) signal-processing layer — attention, graph algorithms, and compression — adding contrastive learning on top.

See docs/adr/ADR-024-contrastive-csi-embedding-model.md for full architectural details.

📦 Installation

Guided Installer — Interactive hardware detection and profile selection ./install.sh

The installer walks through 7 steps: system detection, toolchain check, WiFi hardware scan, profile recommendation, dependency install, build, and verification.

Profile What it installs Size Requirements

verify Pipeline verification only ~5 MB Python 3.8+

python Full Python API server + sensing ~500 MB Python 3.8+

rust Rust pipeline (~810x faster) ~200 MB Rust 1.70+

browser WASM for in-browser execution ~10 MB Rust + wasm-pack

iot ESP32 sensor mesh + aggregator varies Rust + ESP-IDF

docker Docker-based deployment ~1 GB Docker

field WiFi-Mat disaster response kit ~62 MB Rust + wasm-pack

full Everything available ~2 GB All toolchains

Non-interactive

./install.sh --profile rust --yes

Hardware check only

./install.sh --check-only

From Source — Rust (primary) or Python git clone https://github.com/ruvnet/RuView.git cd RuView

Rust (primary — 810x faster)

cd rust-port/wifi-densepose-rs cargo build --release cargo test --workspace

Python (legacy v1)

pip install -r requirements.txt pip install -e .

Or via pip

pip install wifi-densepose pip install wifi-densepose[gpu] # GPU acceleration pip install wifi-densepose[all] # All optional deps

Docker — Pre-built images, no toolchain needed

Rust sensing server (132 MB — recommended)

docker pull ruvnet/wifi-densepose:latest docker run -p 3000:3000 -p 3001:3001 -p 5005:5005/udp ruvnet/wifi-densepose:latest

Python sensing pipeline (569 MB)

docker pull ruvnet/wifi-densepose:python docker run -p 8765:8765 -p 8080:8080 ruvnet/wifi-densepose:python

Both via docker-compose

cd docker && docker compose up

Export RVF model

docker run --rm -v $(pwd):/out ruvnet/wifi-densepose:latest --export-rvf /out/model.rvf

Image Tag Platforms Ports

ruvnet/wifi-densepose latest, rust linux/amd64, linux/arm64 3000 (REST), 3001 (WS), 5005/udp (ESP32)

ruvnet/wifi-densepose python linux/amd64 8765 (WS), 8080 (UI)

System Requirements

Rust: 1.70+ (primary runtime — install via rustup)

Python: 3.8+ (for verification and legacy v1 API)

OS: Linux (Ubuntu 18.04+), macOS (10.15+), Windows 10+

Memory: Minimum 4GB RAM, Recommended 8GB+

Storage: 2GB free space for models and data

Network: WiFi interface with CSI capability (optional — installer detects what you have)

GPU: Optional (NVIDIA CUDA or Apple Metal)

Rust Crates — Individual crates on crates.io The Rust workspace consists of 15 crates, all published to crates.io:

Add individual crates to your Cargo.toml

cargo add wifi-densepose-core # Types, traits, errors cargo add wifi-densepose-signal # CSI signal processing (6 SOTA algorithms) cargo add wifi-densepose-nn # Neural inference (ONNX, PyTorch, Candle) cargo add wifi-densepose-vitals # Vital sign extraction (breathing + heart rate) cargo add wifi-densepose-mat # Disaster response (MAT survivor detection) cargo add wifi-densepose-hardware # ESP32, Intel 5300, Atheros sensors cargo add wifi-densepose-train # Training pipeline (MM-Fi dataset) cargo add wifi-densepose-wifiscan # Multi-BSSID WiFi scanning cargo add wifi-densepose-ruvector # RuVector v2.0.4 integration layer (ADR-017)

Crate Description RuVector crates.io

wifi-densepose-core Foundation types, traits, and utilities

wifi-densepose-signal SOTA CSI signal processing (SpotFi, FarSense, Widar 3.0) mincut, attn-mincut, attention, solver

wifi-densepose-nn Multi-backend inference (ONNX, PyTorch, Candle)

wifi-densepose-train Training pipeline with MM-Fi dataset (NeurIPS 2023) All 5

wifi-densepose-mat Mass Casualty Assessment Tool (disaster survivor detection) solver, temporal-tensor

wifi-densepose-ruvector RuVector v2.0.4 integration layer — 7 signal+MAT integration points (ADR-017) All 5

wifi-densepose-vitals Vital signs: breathing (6-30 BPM), heart rate (40-120 BPM)

wifi-densepose-hardware ESP32, Intel 5300, Atheros CSI sensor interfaces

wifi-densepose-wifiscan Multi-BSSID WiFi scanning (Windows, macOS, Linux)

wifi-densepose-wasm WebAssembly bindings for browser deployment

wifi-densepose-sensing-server Axum server: UDP ingestion, WebSocket broadcast

wifi-densepose-cli Command-line tool for MAT disaster scanning

wifi-densepose-api REST + WebSocket API layer

wifi-densepose-config Configuration management

wifi-densepose-db Database persistence (PostgreSQL, SQLite, Redis)

All crates integrate with RuVector v2.0.4 — see AI Backbone below.

🚀 Quick Start

First API call in 3 commands

1. Install

Fastest path — Docker

docker pull ruvnet/wifi-densepose:latest docker run -p 3000:3000 ruvnet/wifi-densepose:latest

Or from source (Rust)

./install.sh --profile rust --yes

2. Start the System

from wifi_densepose import WiFiDensePose

system = WiFiDensePose() system.start() poses = system.get_latest_poses() print(f"Detected {len(poses)} persons") system.stop()

3. REST API

Health check

curl http://localhost:3000/health

Latest sensing frame

curl http://localhost:3000/api/v1/sensing/latest

Vital signs

curl http://localhost:3000/api/v1/vital-signs

Pose estimation

curl http://localhost:3000/api/v1/pose/current

Server info

curl http://localhost:3000/api/v1/info

4. Real-time WebSocket

import asyncio, websockets, json

async def stream(): async with websockets.connect("ws://localhost:3001/ws/sensing") as ws: async for msg in ws: data = json.loads(msg) print(f"Persons: {len(data.get('persons', []))}")

asyncio.run(stream())

📋 Table of Contents

📡 Signal Processing & Sensing — From raw WiFi frames to vital signs The signal processing stack transforms raw WiFi Channel State Information into actionable human sensing data. Starting from 56-192 subcarrier complex values captured at 20 Hz, the pipeline applies research-grade algorithms (SpotFi phase correction, Hampel outlier rejection, Fresnel zone modeling) to extract breathing rate, heart rate, motion level, and multi-person body pose — all in pure Rust with zero external ML dependencies.

Section Description Docs

Key Features Sensing, Intelligence, and Performance & Deployment capabilities —

How It Works End-to-end pipeline: radio waves → CSI capture → signal processing → AI → pose + vitals —

ESP32-S3 Hardware Pipeline 20 Hz CSI streaming, binary frame parsing, flash & provision ADR-018 · Tutorial #34

Vital Sign Detection Breathing 6-30 BPM, heartbeat 40-120 BPM, FFT peak detection ADR-021

WiFi Scan Domain Layer 8-stage RSSI pipeline, multi-BSSID fingerprinting, Windows WiFi ADR-022 · Tutorial #36

WiFi-Mat Disaster Response Search & rescue, START triage, 3D localization through debris ADR-001 · User Guide

SOTA Signal Processing SpotFi, Hampel, Fresnel, STFT spectrogram, subcarrier selection, BVP ADR-014

🧠 Models & Training — DensePose pipeline, RVF containers, SONA adaptation, RuVector integration The neural pipeline uses a graph transformer with cross-attention to map CSI feature matrices to 17 COCO body keypoints and DensePose UV coordinates. Models are packaged as single-file .rvf containers with progressive loading (Layer A instant, Layer B warm, Layer C full). SONA (Self-Optimizing Neural Architecture) enables continuous on-device adaptation via micro-LoRA + EWC++ without catastrophic forgetting. Signal processing is powered by 5 RuVector crates (v2.0.4) with 7 integration points across the Rust workspace, plus 6 additional vendored crates for inference and graph intelligence.

Section Description Docs

RVF Model Container Binary packaging with Ed25519 signing, progressive 3-layer loading, SIMD quantization ADR-023

Training & Fine-Tuning 8-phase pure Rust pipeline (7,832 lines), MM-Fi/Wi-Pose pre-training, 6-term composite loss, SONA LoRA ADR-023

RuVector Crates 11 vendored Rust crates from ruvector: attention, min-cut, solver, GNN, HNSW, temporal compression, sparse inference GitHub · Source

AI Backbone (RuVector) 5 AI capabilities replacing hand-tuned thresholds: attention, graph min-cut, sparse solvers, tiered compression crates.io

Self-Learning WiFi AI (ADR-024) Contrastive self-supervised learning, room fingerprinting, anomaly detection, 55 KB model ADR-024

Cross-Environment Generalization (ADR-027) Domain-adversarial training, geometry-conditioned inference, hardware normalization, zero-shot deployment ADR-027

🖥️ Usage & Configuration — CLI flags, API endpoints, hardware setup The Rust sensing server is the primary interface, offering a comprehensive CLI with flags for data source selection, model loading, training, benchmarking, and RVF export. A REST API (Axum) and WebSocket server provide real-time data access. The Python v1 CLI remains available for legacy workflows.

Section Description Docs

CLI Usage --source, --train, --benchmark, --export-rvf, --model, --progressive —

REST API & WebSocket 6 REST endpoints (sensing, vitals, BSSID, SONA), WebSocket real-time stream —

Hardware Support ESP32-S3 ($8), Intel 5300 ($15), Atheros AR9580 ($20), Windows RSSI ($0) ADR-012 · ADR-013

⚙️ Development & Testing — 542+ tests, CI, deployment The project maintains 542+ pure-Rust tests across 7 crate suites with zero mocks — every test runs against real algorithm implementations. Hardware-free simulation mode (--source simulate) enables full-stack testing without physical devices. Docker images are published on Docker Hub for zero-setup deployment.

Section Description Docs

Testing 7 test suites: sensing-server (229), signal (83), mat (139), wifiscan (91), RVF (16), vitals (18) —

Deployment Docker images (132 MB Rust / 569 MB Python), docker-compose, env vars —

Contributing Fork → branch → test → PR workflow, Rust and Python dev setup —

📊 Performance & Benchmarks — Measured throughput, latency, resource usage All benchmarks are measured on the Rust sensing server using cargo bench and the built-in --benchmark CLI flag. The Rust v2 implementation delivers 810x end-to-end speedup over the Python v1 baseline, with motion detection reaching 5,400x improvement. The vital sign detector processes 11,665 frames/second in a single-threaded benchmark.

Section Description Key Metric

Performance Metrics Vital signs, CSI pipeline, motion detection, Docker image, memory 11,665 fps vitals · 54K fps pipeline

Rust vs Python Side-by-side benchmarks across 5 operations 810x full pipeline speedup

📄 Meta — License, changelog, support WiFi DensePose is MIT-licensed open source, developed by ruvnet. The project has been in active development since March 2025, with 3 major releases delivering the Rust port, SOTA signal processing, disaster response module, and end-to-end training pipeline.

Section Description Link

Changelog v3.0.0 (AETHER AI + Docker), v2.0.0 (Rust port + SOTA + WiFi-Mat) CHANGELOG.md

License MIT License LICENSE

Support Bug reports, feature requests, community discussion Issues · Discussions

🌍 Cross-Environment Generalization (ADR-027 — Project MERIDIAN) — Train once, deploy in any room without retraining

What How it works Why it matters

Gradient Reversal Layer An adversarial classifier tries to guess which room the signal came from; the main network is trained to fool it Forces the model to discard room-specific shortcuts

Geometry Encoder (FiLM) Transmitter/receiver positions are Fourier-encoded and injected as scale+shift conditioning on every layer The model knows where the hardware is, so it doesn't need to memorize layout

Hardware Normalizer Resamples any chipset's CSI to a canonical 56-subcarrier format with standardized amplitude Intel 5300 and ESP32 data look identical to the model

Virtual Domain Augmentation Generates synthetic environments with random room scale, wall reflections, scatterers, and noise profiles Training sees 1000s of rooms even with data from just 2-3

Rapid Adaptation (TTT) Contrastive test-time training with LoRA weight generation from a few unlabeled frames Zero-shot deployment — the model self-tunes on arrival

Cross-Domain Evaluator Leave-one-out evaluation across all training environments with per-environment PCK/OKS metrics Proves generalization, not just memorization

Architecture

CSI Frame [any chipset] │ ▼ HardwareNormalizer ──→ canonical 56 subcarriers, N(0,1) amplitude │ ▼ CSI Encoder (existing) ──→ latent features │ ├──→ Pose Head ──→ 17-joint pose (environment-invariant) │ ├──→ Gradient Reversal Layer ──→ Domain Classifier (adversarial) │ λ ramps 0→1 via cosine/exponential schedule │ └──→ Geometry Encoder ──→ FiLM conditioning (scale + shift) Fourier positional encoding → DeepSets → per-layer modulation

Security hardening:

Bounded calibration buffer (max 10,000 frames) prevents memory exhaustion

adapt() returns Result<_, AdaptError> — no panics on bad input

Atomic instance counter ensures unique weight initialization across threads

Division-by-zero guards on all augmentation parameters

See docs/adr/ADR-027-cross-environment-domain-generalization.md for full architectural details.

🔍 Independent Capability Audit (ADR-028) — 1,031 tests, SHA-256 proof, self-verifying witness bundle A 3-agent parallel audit independently verified every claim in this repository — ESP32 hardware, signal processing, neural networks, training pipeline, deployment, and security. Results:

Rust tests: 1,031 passed, 0 failed Python proof: VERDICT: PASS (SHA-256: 8c0680d7...) Bundle verify: 7/7 checks PASS

33-row attestation matrix: 31 capabilities verified YES, 2 not measured at audit time (benchmark throughput, Kubernetes deploy).

Verify it yourself (no hardware needed):

Run all tests

cd rust-port/wifi-densepose-rs && cargo test --workspace --no-default-features

Run the deterministic proof

python v1/data/proof/verify.py

Generate + verify the witness bundle

bash scripts/generate-witness-bundle.sh cd dist/witness-bundle-ADR028-*/ && bash VERIFY.sh

Document What it contains

ADR-028 Full audit: ESP32 specs, signal algorithms, NN architectures, training phases, deployment infra

Witness Log 11 reproducible verification steps + 33-row attestation matrix with evidence per row

generate-witness-bundle.sh Creates self-contained tar.gz with test logs, proof output, firmware hashes, crate versions, VERIFY.sh

📡 Multistatic Sensing (ADR-029/030/031 — Project RuvSense + RuView) — Multiple ESP32 nodes fuse viewpoints for production-grade pose, tracking, and exotic sensing A single WiFi receiver can track people, but has blind spots — limbs behind the torso are invisible, depth is ambiguous, and two people at similar range create overlapping signals. RuvSense solves this by coordinating multiple ESP32 nodes into a multistatic mesh where every node acts as both transmitter and receiver, creating N×(N-1) measurement links from N devices.

What it does in plain terms:

4 ESP32-S3 nodes ($48 total) provide 12 TX-RX measurement links covering 360 degrees

Each node hops across WiFi channels 1/6/11, tripling effective bandwidth from 20→60 MHz

Coherence gating rejects noisy frames automatically — no manual tuning, stable for days

Two-person tracking at 20 Hz with zero identity swaps over 10 minutes

The room itself becomes a persistent model — the system remembers, predicts, and explains

Three ADRs, one pipeline:

ADR Codename What it adds

ADR-029 RuvSense Channel hopping, TDM protocol, multi-node fusion, coherence gating, 17-keypoint Kalman tracker

ADR-030 RuvSense Field Room electromagnetic eigenstructure (SVD), RF tomography, longitudinal drift detection, intention prediction, gesture recognition, adversarial detection

ADR-031 RuView Cross-viewpoint attention with geometric bias, viewpoint diversity optimization, embedding-level fusion

Architecture

4x ESP32-S3 nodes ($48) TDM: each transmits in turn, all others receive │ Channel hop: ch1→ch6→ch11 per dwell (50ms) ▼ Per-Node Signal Processing Phase sanitize → Hampel → BVP → subcarrier select │ (ADR-014, unchanged per viewpoint) ▼ Multi-Band Frame Fusion 3 channels × 56 subcarriers = 168 virtual subcarriers │ Cross-channel phase alignment via NeumannSolver ▼ Multistatic Viewpoint Fusion N nodes → attention-weighted fusion → single embedding │ Geometric bias from node placement angles ▼ Coherence Gate Accept / PredictOnly / Reject / Recalibrate │ Prevents model drift, stable for days ▼ Persistent Field Model SVD baseline → body = observation - environment │ RF tomography, drift detection, intention signals ▼ Pose Tracker + DensePose 17-keypoint Kalman, re-ID via AETHER embeddings Multi-person min-cut separation, zero ID swaps

Seven Exotic Sensing Tiers (ADR-030)

Tier Capability What it detects

1 Field Normal Modes Room electromagnetic eigenstructure via SVD

2 Coarse RF Tomography 3D occupancy volume from link attenuations

3 Intention Lead Signals Pre-movement prediction 200-500ms before action

4 Longitudinal Biomechanics Personal movement changes over days/weeks

5 Cross-Room Continuity Identity preserved across rooms without cameras

6 Invisible Interaction Multi-user gesture control through walls

7 Adversarial Detection Physically impossible signal identification

Acceptance Test

Metric Threshold What it proves

Torso keypoint jitter < 30mm RMS Precision sufficient for applications

Identity swaps 0 over 10 minutes (12,000 frames) Reliable multi-person tracking

Update rate 20 Hz (50ms cycle) Real-time response

Breathing SNR

10 dB at 3m Small-motion sensitivity confirmed

New Rust modules (9,000+ lines)

Crate New modules Purpose

wifi-densepose-signal ruvsense/ (10 modules) Multiband fusion, phase alignment, multistatic fusion, coherence, field model, tomography, longitudinal drift, intention detection

wifi-densepose-ruvector viewpoint/ (5 modules) Cross-viewpoint attention with geometric bias, diversity index, coherence gating, fusion orchestrator

wifi-densepose-hardware esp32/tdm.rs TDM sensing protocol, sync beacons, clock drift compensation

Firmware extensions (C, backward-compatible)

File Addition

csi_collector.c Channel hop table, timer-driven hop, NDP injection stub

nvs_config.c 5 new NVS keys: hop_count, channel_list, dwell_ms, tdm_slot, tdm_node_count

DDD Domain Model — 6 bounded contexts: Multistatic Sensing, Coherence, Pose Tracking, Field Model, Cross-Room Identity, Adversarial Detection. Full specification: docs/ddd/ruvsense-domain-model.md.

See the ADR documents for full architectural details, GOAP integration plans, and research references.

🔮 Signal-Line Protocol (CRV) 6-Stage CSI Signal Line

Maps the CRV (Coordinate Remote Viewing) signal-line methodology to WiFi CSI processing via ruvector-crv:

Stage CRV Name WiFi CSI Mapping ruvector Component

I Ideograms Raw CSI gestalt (manmade/natural/movement/energy) Poincare ball hyperbolic embeddings

II Sensory Amplitude textures, phase patterns, frequency colors Multi-head attention vectors

III Dimensional AP mesh spatial topology, node geometry GNN graph topology

IV Emotional/AOL Coherence gating — signal vs noise separation SNN temporal encoding

V Interrogation Cross-stage probing — query pose against CSI history Differentiable search

VI 3D Model Composite person estimation, MinCut partitioning Graph partitioning

Cross-Session Convergence: When multiple AP clusters observe the same person, CRV convergence analysis finds agreement in their signal embeddings — directly mapping to cross-room identity continuity.

use wifi_densepose_ruvector::crv::WifiCrvPipeline;

let mut pipeline = WifiCrvPipeline::new(WifiCrvConfig::default()); pipeline.create_session("room-a", "person-001")?;

// Process CSI frames through 6-stage pipeline let result = pipeline.process_csi_frame("room-a", &amplitudes, &phases)?; // result.gestalt = Movement, confidence = 0.87 // result.sensory_embedding = [0.12, -0.34, ...]

// Cross-room identity matching via convergence let convergence = pipeline.find_cross_room_convergence("person-001", 0.75)?;

Architecture:

CsiGestaltClassifier — Maps CSI amplitude/phase patterns to 6 gestalt types

CsiSensoryEncoder — Extracts texture/color/temperature/luminosity features from subcarriers

MeshTopologyEncoder — Encodes AP mesh as GNN graph (Stage III)

CoherenceAolDetector — Maps coherence gate states to AOL noise detection (Stage IV)

WifiCrvPipeline — Orchestrates all 6 stages into unified sensing session

📡 Signal Processing & Sensing

📡 ESP32-S3 Hardware Pipeline (ADR-018) — 28 Hz CSI streaming, flash & provision A single ESP32-S3 board (~$9) captures WiFi signal data 28 times per second and streams it over UDP. A host server can visualize and record the data, but the ESP32 can also run on its own — detecting presence, measuring breathing and heart rate, and alerting on falls without any server at all.

ESP32-S3 node UDP/5005 Host server (optional) ┌───────────────────────┐ ──────────> ┌──────────────────────┐ │ Captures WiFi signals │ binary frames │ Parses frames │ │ 28 Hz, up to 192 sub- │ or 32-byte │ Visualizes poses │ │ carriers per frame │ vitals packets │ Records CSI data │ │ │ │ REST API + WebSocket │ │ On-device (optional): │ └──────────────────────┘ │ Presence detection │ │ Breathing + heart rate│ │ Fall detection │ │ WASM custom modules │ └───────────────────────┘

Metric Measured on hardware

CSI frame rate 28.5 Hz (channel 5, BW20)

Subcarriers per frame 64 / 128 / 192 (depends on WiFi mode)

UDP latency < 1 ms on local network

Presence detection range Reliable at 3 m through walls

Binary size 947 KB (fits in 1 MB flash partition)

Boot to ready ~3.9 seconds

Flash and provision

Download a pre-built binary — no build toolchain needed:

Release What's included Tag

v0.2.0 Stable — raw CSI streaming, multi-node TDM, channel hopping v0.2.0-esp32

v0.3.0-alpha Alpha — adds on-device edge intelligence and WASM modules (ADR-039, ADR-040) v0.3.0-alpha-esp32

1. Flash the firmware to your ESP32-S3

python -m esptool --chip esp32s3 --port COM7 --baud 460800
write_flash --flash_mode dio --flash_size 8MB
0x0 bootloader.bin 0x8000 partition-table.bin 0x10000 esp32-csi-node.bin

2. Set WiFi credentials and server address (stored in flash, survives reboots)

python firmware/esp32-csi-node/provision.py --port COM7
--ssid "YourWiFi" --password "secret" --target-ip 192.168.1.20

3. (Optional) Start the host server to visualize data

cargo run -p wifi-densepose-sensing-server -- --http-port 3000 --source auto

Open http://localhost:3000

Multi-node mesh

For better accuracy and room coverage, deploy 3-6 nodes with time-division multiplexing (TDM) so they take turns transmitting:

Node 0 of a 3-node mesh

python firmware/esp32-csi-node/provision.py --port COM7
--ssid "YourWiFi" --password "secret" --target-ip 192.168.1.20
--node-id 0 --tdm-slot 0 --tdm-total 3

Node 1

python firmware/esp32-csi-node/provision.py --port COM8
--ssid "YourWiFi" --password "secret" --target-ip 192.168.1.20
--node-id 1 --tdm-slot 1 --tdm-total 3

Nodes can also hop across WiFi channels (1, 6, 11) to increase sensing bandwidth — configured via ADR-029 channel hopping.

On-device intelligence (v0.3.0-alpha)

The alpha firmware can analyze signals locally and send compact results instead of raw data. This means the ESP32 works standalone — no server needed for basic sensing. Disabled by default for backward compatibility.

Tier What it does RAM used

0 Off — streams raw CSI only (same as v0.2.0) 0 KB

1 Cleans up signals, picks the best subcarriers, compresses data (saves 30-50% bandwidth) ~30 KB

2 Everything in Tier 1 + detects presence, measures breathing and heart rate, detects falls ~33 KB

3 Everything in Tier 2 + runs custom WASM modules (gesture recognition, intrusion detection, and 63 more) ~160 KB/module

Enable without reflashing — just reprovision:

Turn on Tier 2 (vitals) on an already-flashed node

python firmware/esp32-csi-node/provision.py --port COM7
--ssid "YourWiFi" --password "secret" --target-ip 192.168.1.20
--edge-tier 2

Fine-tune detection thresholds

python firmware/esp32-csi-node/provision.py --port COM7
--edge-tier 2 --vital-int 500 --fall-thresh 5000 --subk-count 16

When Tier 2 is active, the node sends a 32-byte vitals packet once per second containing: presence, motion level, breathing BPM, heart rate BPM, confidence scores, fall alert flag, and occupancy count.

See firmware/esp32-csi-node/README.md, ADR-039, ADR-044, and Tutorial #34.

🦀 Rust Implementation (v2) — 810x faster, 54K fps pipeline Performance Benchmarks (Validated)

Operation Python (v1) Rust (v2) Speedup

CSI Preprocessing (4x64) ~5ms 5.19 µs ~1000x

Phase Sanitization (4x64) ~3ms 3.84 µs ~780x

Feature Extraction (4x64) ~8ms 9.03 µs ~890x

Motion Detection ~1ms 186 ns ~5400x

Full Pipeline ~15ms 18.47 µs ~810x

Vital Signs N/A 86 µs 11,665 fps

Resource Python (v1) Rust (v2)

Memory ~500 MB ~100 MB

Docker Image 569 MB 132 MB

Tests 41 542+

WASM Support No Yes

cd rust-port/wifi-densepose-rs cargo build --release cargo test --workspace cargo bench --package wifi-densepose-signal

💓 Vital Sign Detection (ADR-021) — Breathing and heartbeat via FFT

Capability Range Method

Breathing Rate 6-30 BPM (0.1-0.5 Hz) Bandpass filter + FFT peak detection

Heart Rate 40-120 BPM (0.8-2.0 Hz) Bandpass filter + FFT peak detection

Sampling Rate 20 Hz (ESP32 CSI) Real-time streaming

Confidence 0.0-1.0 per sign Spectral coherence + signal quality

./target/release/sensing-server --source simulate --http-port 3000 --ws-port 3001 --ui-path ../../ui curl http://localhost:3000/api/v1/vital-signs

See ADR-021.

📡 WiFi Scan Domain Layer (ADR-022/025) — 8-stage RSSI pipeline for Windows, macOS, and Linux WiFi

Stage Purpose

Predictive Gating Pre-filter scan results using temporal prediction

Attention Weighting Weight BSSIDs by signal relevance

Spatial Correlation Cross-AP spatial signal correlation

Motion Estimation Detect movement from RSSI variance

Breathing Extraction Extract respiratory rate from sub-Hz oscillations

Quality Gating Reject low-confidence estimates

Fingerprint Matching Location and posture classification via RF fingerprints

Orchestration Fuse all stages into unified sensing output

cargo test -p wifi-densepose-wifiscan

See ADR-022 and Tutorial #36.

🚨 WiFi-Mat: Disaster Response — Search & rescue, START triage, 3D localization WiFi signals penetrate non-metallic debris (concrete, wood, drywall) where cameras and thermal sensors cannot reach. The WiFi-Mat module (wifi-densepose-mat, 139 tests) uses CSI analysis to detect survivors trapped under rubble, classify their condition using the START triage protocol, and estimate their 3D position — giving rescue teams actionable intelligence within seconds of deployment.

Capability How It Works Performance Target

Breathing Detection Bandpass 0.07-1.0 Hz + Fresnel zone modeling detects chest displacement of 5-10mm at 5 GHz 4-60 BPM, <500ms latency

Heartbeat Detection Micro-Doppler shift extraction from fine-grained CSI phase variation Via ruvector-temporal-tensor

3D Localization Multi-AP triangulation + CSI fingerprint matching + depth estimation through rubble layers 3-5m penetration

START Triage Ensemble classifier votes on breathing + movement + vital stability → P1-P4 priority <1% false negative

Zone Scanning 16+ concurrent scan zones with periodic re-scan and audit logging Full disaster site

Triage classification (START protocol compatible):

Status Color Detection Criteria Priority

Immediate Red Breathing detected, no movement P1

Delayed Yellow Movement + breathing, stable vitals P2

Minor Green Strong movement, responsive patterns P3

Deceased Black No vitals for >30 min continuous scan P4

Deployment modes: portable (single TX/RX handheld), distributed (multiple APs around collapse site), drone-mounted (UAV scanning), vehicle-mounted (mobile command post).

use wifi_densepose_mat::{DisasterResponse, DisasterConfig, DisasterType, ScanZone, ZoneBounds};

let config = DisasterConfig::builder() .disaster_type(DisasterType::Earthquake) .sensitivity(0.85) .max_depth(5.0) .build();

let mut response = DisasterResponse::new(config); response.initialize_event(location, "Building collapse")?; response.add_zone(ScanZone::new("North Wing", ZoneBounds::rectangle(0.0, 0.0, 30.0, 20.0)))?; response.start_scanning().await?;

Safety guarantees: fail-safe defaults (assume life present on ambiguous signals), redundant multi-algorithm voting, complete audit trail, offline-capable (no network required).

WiFi-Mat User Guide | ADR-001 | Domain Model

🔬 SOTA Signal Processing (ADR-014) — 6 research-grade algorithms The signal processing layer bridges the gap between raw commodity WiFi hardware output and research-grade sensing accuracy. Each algorithm addresses a specific limitation of naive CSI processing — from hardware-induced phase corruption to environment-dependent multipath interference. All six are implemented in wifi-densepose-signal/src/ with deterministic tests and no mock data.

Algorithm What It Does Why It Matters Math Source

Conjugate Multiplication Multiplies CSI antenna pairs: H₁[k] × conj(H₂[k]) Cancels CFO, SFO, and packet detection delay that corrupt raw phase — preserves only environment-caused phase differences CSI_ratio[k] = H₁[k] * conj(H₂[k]) SpotFi (SIGCOMM 2015)

Hampel Filter Replaces outliers using running median ± scaled MAD Z-score uses mean/std which are corrupted by the very outliers it detects (masking effect). Hampel uses median/MAD, resisting up to 50% contamination σ̂ = 1.4826 × MAD Standard DSP; WiGest (2015)

Fresnel Zone Model Models signal variation from chest displacement crossing Fresnel zone boundaries Zero-crossing counting fails in multipath-rich environments. Fresnel predicts where breathing should appear based on TX-RX-body geometry ΔΦ = 2π × 2Δd / λ, A = |sin(ΔΦ/2)| FarSense (MobiCom 2019)

CSI Spectrogram Sliding-window FFT (STFT) per subcarrier → 2D time-frequency matrix Breathing = 0.2-0.4 Hz band, walking = 1-2 Hz, static = noise. 2D structure enables CNN spatial pattern recognition that 1D features miss S[t,f] = |Σₙ x[n] w[n-t] e^{-j2πfn}|² Standard since 2018

Subcarrier Selection Ranks subcarriers by motion sensitivity (variance ratio) and selects top-K Not all subcarriers respond to motion — some sit in multipath nulls. Selecting the 10-20 most sensitive improves SNR by 6-10 dB sensitivity[k] = var_motion / var_static WiDance (MobiCom 2017)

Body Velocity Profile Extracts velocity distribution from Doppler shifts across subcarriers BVP is domain-independent — same velocity profile regardless of room layout, furniture, or AP placement. Basis for cross-environment recognition BVP[v,t] = Σₖ |STFTₖ[v,t]| Widar 3.0 (MobiSys 2019)

Processing pipeline order: Raw CSI → Conjugate multiplication (phase cleaning) → Hampel filter (outlier removal) → Subcarrier selection (top-K) → CSI spectrogram (time-frequency) → Fresnel model (breathing) + BVP (activity)

See ADR-014 for full mathematical derivations.

🧠 Models & Training

🤖 AI Backbone: RuVector — Attention, graph algorithms, and edge-AI compression powering the sensing pipeline Raw WiFi signals are noisy, redundant, and environment-dependent. RuVector is the AI intelligence layer that transforms them into clean, structured input for the DensePose neural network. It uses attention mechanisms to learn which signals to trust, graph algorithms that automatically discover which WiFi channels are sensitive to body motion, and compressed representations that make edge inference possible on an $8 microcontroller.

Without RuVector, WiFi DensePose would need hand-tuned thresholds, brute-force matrix math, and 4x more memory — making real-time edge inference impossible.

Raw WiFi CSI (56 subcarriers, noisy) | +-- ruvector-mincut ---------- Which channels carry body-motion signal? (learned graph partitioning) +-- ruvector-attn-mincut ----- Which time frames are signal vs noise? (attention-gated filtering) +-- ruvector-attention ------- How to fuse multi-antenna data? (learned weighted aggregation) | v Clean, structured signal --> DensePose Neural Network --> 17-keypoint body pose --> FFT Vital Signs -----------> breathing rate, heart rate --> ruvector-solver ------------> physics-based localization

The wifi-densepose-ruvector crate (ADR-017) connects all 7 integration points:

AI Capability What It Replaces RuVector Crate Result

Self-optimizing channel selection Hand-tuned thresholds that break when rooms change ruvector-mincut Graph min-cut adapts to any environment automatically

Attention-based signal cleaning Fixed energy cutoffs that miss subtle breathing ruvector-attn-mincut Learned gating amplifies body signals, suppresses noise

Learned signal fusion Simple averaging where one bad channel corrupts all ruvector-attention Transformer-style attention downweights corrupted channels

Physics-informed localization Expensive nonlinear solvers ruvector-solver Sparse least-squares Fresnel geometry in real-time

O(1) survivor triangulation O(N^3) matrix inversion ruvector-solver Neumann series linearization for instant position updates

75% memory compression 13.4 MB breathing buffers that overflow edge devices ruvector-temporal-tensor Tiered 3-8 bit quantization fits 60s of vitals in 3.4 MB

See issue #67 for a deep dive with code examples, or cargo add wifi-densepose-ruvector to use it directly.

📦 RVF Model Container — Single-file deployment with progressive loading The RuVector Format (RVF) packages an entire trained model — weights, HNSW indexes, quantization codebooks, SONA adaptation deltas, and WASM inference runtime — into a single self-contained binary file. No external dependencies are needed at deployment time.

Container structure:

┌──────────────────────────────────────────────────────┐ │ RVF Container (.rvf) │ │ │ │ ┌─────────────┐ 64-byte header per segment │ │ │ Manifest │ Magic: 0x52564653 ("RVFS") │ │ ├─────────────┤ Type + content hash + compression │ │ │ Weights │ Model parameters (f32/f16/u8) │ │ ├─────────────┤ │ │ │ HNSW Index │ Vector search index │ │ ├─────────────┤ │ │ │ Quant │ Quantization codebooks │ │ ├─────────────┤ │ │ │ SONA Profile │ LoRA deltas + EWC++ Fisher matrix │ │ ├─────────────┤ │ │ │ Witness │ Ed25519 training proof │ │ ├─────────────┤ │ │ │ Vitals Config│ Breathing/HR filter parameters │ │ └─────────────┘ │ └──────────────────────────────────────────────────────┘

Deployment targets:

Target Quantization Size Load Time Use Case

ESP32 / IoT int4 ~0.7 MB <5ms (Layer A) Presence + breathing only

Mobile / WebView int8 ~6 MB ~200ms (Layer B) Pose estimation on phone

Browser (WASM) int8 ~10 MB ~500ms (Layer B) In-browser demo

Field (WiFi-Mat) fp16 ~62 MB ~2s (Layer C) Full DensePose + disaster triage

Server / Cloud f32 ~50+ MB ~3s (Layer C) Training + full inference

Property Detail

Format Segment-based binary, 20+ segment types, CRC32 integrity per segment

Progressive Loading Layer A (<5ms): manifest + entry points → Layer B (100ms-1s): hot weights + adjacency → Layer C (seconds): full graph

Signing Ed25519 training proofs for verifiable provenance — chain of custody from training data to deployed model

Quantization Per-segment temperature-tiered: f32 (full), f16 (half), u8 (int8), int4 — with SIMD-accelerated distance computation

CLI --export-rvf (generate), --load-rvf (config), --save-rvf (persist), --model (inference), --progressive (3-layer load)

Export model package

./target/release/sensing-server --export-rvf wifi-densepose-v1.rvf

Load and run with progressive loading

./target/release/sensing-server --model wifi-densepose-v1.rvf --progressive

Export via Docker

docker run --rm -v $(pwd):/out ruvnet/wifi-densepose:latest --export-rvf /out/model.rvf

Built on the rvf crate family (rvf-types, rvf-wire, rvf-manifest, rvf-index, rvf-quant, rvf-crypto, rvf-runtime). See ADR-023.

🧬 Training & Fine-Tuning — MM-Fi/Wi-Pose pre-training, SONA adaptation The training pipeline implements 8 phases in pure Rust (7,832 lines, zero external ML dependencies). It trains a graph transformer with cross-attention to map CSI feature matrices to 17 COCO body keypoints and DensePose UV coordinates — following the approach from the CMU "DensePose From WiFi" paper (arXiv:2301.00250). RuVector crates provide the core building blocks: ruvector-attention for cross-attention layers, ruvector-mincut for multi-person matching, and ruvector-temporal-tensor for CSI buffer compression.

Three-tier data strategy:

Tier Method Purpose RuVector Integration

1. Pre-train MM-Fi + Wi-Pose public datasets Cross-environment generalization (multi-subject, multi-room) ruvector-temporal-tensor compresses CSI windows (114→56 subcarrier resampling)

2. Fine-tune ESP32 CSI + camera pseudo-labels Environment-specific multipath adaptation ruvector-solver for Fresnel geometry, ruvector-attn-mincut for subcarrier gating

3. SONA adapt Micro-LoRA (rank-4) + EWC++ Continuous on-device learning without catastrophic forgetting SONA architecture (Self-Optimizing Neural Architecture)

Training pipeline components:

Phase Module What It Does RuVector Crate

1 dataset.rs (850 lines) MM-Fi .npy + Wi-Pose .mat loaders, subcarrier resampling (114→56, 30→56), windowing ruvector-temporal-tensor

2 graph_transformer.rs (855 lines) COCO BodyGraph (17 kp, 16 edges), AntennaGraph, multi-head CrossAttention, GCN message passing ruvector-attention

3 trainer.rs (881 lines) 6-term composite loss (MSE, CE, UV, temporal, bone, symmetry), SGD+momentum, cosine+warmup, PCK/OKS ruvector-mincut (person matching)

4 sona.rs (639 lines) LoRA adapters (A×B delta), EWC++ Fisher regularization, EnvironmentDetector (3-sigma drift) sona

5 sparse_inference.rs (753 lines) NeuronProfiler hot/cold partitioning, SparseLinear (skip cold rows), INT8/FP16 quantization ruvector-sparse-inference

6 rvf_pipeline.rs (1,027 lines) Progressive 3-layer loader, HNSW index, OverlayGraph, RvfModelBuilder ruvector-core (HNSW)

7 rvf_container.rs (914 lines) Binary container format, 6+ segment types, CRC32 integrity rvf

8 main.rs integration --train, --model, --progressive CLI flags, REST endpoints —

SONA (Self-Optimizing Neural Architecture) — the continuous adaptation system:

Component What It Does Why It Matters

Micro-LoRA (rank-4) Trains small A×B weight deltas instead of full weights 100x fewer parameters to update → runs on ESP32

EWC++ (Fisher matrix) Penalizes changes to important weights from previous environments Prevents catastrophic forgetting when moving between rooms

EnvironmentDetector Monitors CSI feature drift with 3-sigma threshold Auto-triggers adaptation when the model is moved to a new space

Best-epoch snapshot Saves best validation loss weights, restores before export Prevents shipping overfit final-epoch parameters

Pre-train on MM-Fi dataset

./target/release/sensing-server --train --dataset data/ --dataset-type mmfi --epochs 100

Train and export to RVF in one step

./target/release/sensing-server --train --dataset data/ --epochs 100 --save-rvf model.rvf

Via Docker (no toolchain needed)

docker run --rm -v $(pwd)/data:/data ruvnet/wifi-densepose:latest
--train --dataset /data --epochs 100 --export-rvf /data/model.rvf

See ADR-023 · SONA crate · arXiv:2301.00250

🔩 RuVector Crates — 11 vendored signal intelligence crates from github.com/ruvnet/ruvector 5 directly-used crates (v2.0.4, declared in Cargo.toml, 7 integration points):

Crate What It Does Where It's Used in WiFi-DensePose Source

ruvector-attention Scaled dot-product attention, MoE routing, sparse attention model.rs (spatial attention), bvp.rs (sensitivity-weighted velocity profiles) crate

ruvector-mincut Subpolynomial dynamic min-cut O(n^1.5 log n) metrics.rs (DynamicPersonMatcher — multi-person assignment), subcarrier_selection.rs (sensitive/insensitive split) crate

ruvector-attn-mincut Attention-gated spectrogram noise suppression model.rs (antenna attention gating), spectrogram.rs (gate noisy time-frequency bins) crate

ruvector-solver Sparse Neumann series solver O(sqrt(n)) fresnel.rs (TX-body-RX geometry), triangulation.rs (3D localization), subcarrier.rs (sparse interpolation 114→56) crate

ruvector-temporal-tensor Tiered temporal compression (8/7/5/3-bit) dataset.rs (CSI buffer compression), breathing.rs + heartbeat.rs (compressed vital sign spectrograms) crate

6 additional vendored crates (used by training pipeline and inference):

Crate What It Does Source

ruvector-core VectorDB engine, HNSW index, SIMD distance functions, quantization codebooks crate

ruvector-gnn Graph neural network layers, graph attention, EWC-regularized training crate

ruvector-graph-transformer Proof-gated graph transformer with cross-attention crate

ruvector-sparse-inference PowerInfer-style hot/cold neuron partitioning, skip cold rows at runtime crate

ruvector-nervous-system PredictiveLayer, OscillatoryRouter, Hopfield associative memory crate

ruvector-coherence Spectral coherence monitoring, HNSW graph health, Fiedler connectivity crate

The full RuVector ecosystem includes 90+ crates. See github.com/ruvnet/ruvector for the complete library, and vendor/ruvector/ for the vendored source in this project.

🏗️ System Architecture — End-to-end data flow from CSI capture to REST/WebSocket API End-to-End Pipeline

  graph TB
subgraph HW ["📡 Hardware Layer"]
    direction LR
    R1["WiFi Router 1<br/><small>CSI Source</small>"]
    R2["WiFi Router 2<br/><small>CSI Source</small>"]
    R3["WiFi Router 3<br/><small>CSI Source</small>"]
    ESP["ESP32-S3 Mesh<br/><small>20 Hz · 56 subcarriers</small>"]
    WIN["Windows WiFi<br/><small>RSSI scanning</small>"]
end

subgraph INGEST ["⚡ Ingestion"]
    AGG["Aggregator<br/><small>UDP :5005 · ADR-018 frames</small>"]
    BRIDGE["Bridge<br/><small>I/Q → amplitude + phase</small>"]
end

subgraph SIGNAL ["🔬 Signal Processing — RuVector v2.0.4"]
    direction TB
    PHASE["Phase Sanitization<br/><small>SpotFi conjugate multiply</small>"]
    HAMPEL["Hampel Filter<br/><small>Outlier rejection · σ=3</small>"]
    SUBSEL["Subcarrier Selection<br/><small>ruvector-mincut · sensitive/insensitive split</small>"]
    SPEC["Spectrogram<br/><small>ruvector-attn-mincut · gated STFT</small>"]
    FRESNEL["Fresnel Geometry<br/><small>ruvector-solver · TX-body-RX distance</small>"]
    BVP["Body Velocity Profile<br/><small>ruvector-attention · weighted BVP</small>"]
end

subgraph ML ["🧠 Neural Pipeline"]
    direction TB
    GRAPH["Graph Transformer<br/><small>17 COCO keypoints · 16 edges</small>"]
    CROSS["Cross-Attention<br/><small>CSI features → body pose</small>"]
    SONA["SONA Adapter<br/><small>LoRA rank-4 · EWC++</small>"]
end

subgraph VITAL ["💓 Vital Signs"]
    direction LR
    BREATH["Breathing<br/><small>0.1–0.5 Hz · FFT peak</small>"]
    HEART["Heart Rate<br/><small>0.8–2.0 Hz · FFT peak</small>"]
    MOTION["Motion Level<br/><small>Variance + band power</small>"]
end

subgraph API ["🌐 Output Layer"]
    direction LR
    REST["REST API<br/><small>Axum :3000 · 6 endpoints</small>"]
    WS["WebSocket<br/><small>:3001 · real-time stream</small>"]
    ANALYTICS["Analytics<br/><small>Fall · Activity · START triage</small>"]
    UI["Web UI<br/><small>Three.js · Gaussian splats</small>"]
end

R1 & R2 & R3 --> AGG
ESP --> AGG
WIN --> BRIDGE
AGG --> BRIDGE
BRIDGE --> PHASE
PHASE --> HAMPEL
HAMPEL --> SUBSEL
SUBSEL --> SPEC
SPEC --> FRESNEL
FRESNEL --> BVP
BVP --> GRAPH
GRAPH --> CROSS
CROSS --> SONA
SONA --> BREATH & HEART & MOTION
BREATH & HEART & MOTION --> REST & WS & ANALYTICS
WS --> UI

style HW fill:#1a1a2e,stroke:#e94560,color:#eee
style INGEST fill:#16213e,stroke:#0f3460,color:#eee
style SIGNAL fill:#0f3460,stroke:#533483,color:#eee
style ML fill:#533483,stroke:#e94560,color:#eee
style VITAL fill:#2d132c,stroke:#e94560,color:#eee
style API fill:#1a1a2e,stroke:#0f3460,color:#eee

Loading

Signal Processing Detail

  graph LR
subgraph RAW ["Raw CSI Frame"]
    IQ["I/Q Samples<br/><small>56–192 subcarriers × N antennas</small>"]
end

subgraph CLEAN ["Phase Cleanup"]
    CONJ["Conjugate Multiply<br/><small>Remove carrier freq offset</small>"]
    UNWRAP["Phase Unwrap<br/><small>Remove 2π discontinuities</small>"]
    HAMPEL2["Hampel Filter<br/><small>Remove impulse noise</small>"]
end

subgraph SELECT ["Subcarrier Intelligence"]
    MINCUT["Min-Cut Partition<br/><small>ruvector-mincut</small>"]
    GATE["Attention Gate<br/><small>ruvector-attn-mincut</small>"]
end

subgraph EXTRACT ["Feature Extraction"]
    STFT["STFT Spectrogram<br/><small>Time-frequency decomposition</small>"]
    FRESNELZ["Fresnel Zones<br/><small>ruvector-solver</small>"]
    BVPE["BVP Estimation<br/><small>ruvector-attention</small>"]
end

subgraph OUT ["Output Features"]
    AMP["Amplitude Matrix"]
    PHASE2["Phase Matrix"]
    DOPPLER["Doppler Shifts"]
    VITALS["Vital Band Power"]
end

IQ --> CONJ --> UNWRAP --> HAMPEL2
HAMPEL2 --> MINCUT --> GATE
GATE --> STFT --> FRESNELZ --> BVPE
BVPE --> AMP & PHASE2 & DOPPLER & VITALS

style RAW fill:#0d1117,stroke:#58a6ff,color:#c9d1d9
style CLEAN fill:#161b22,stroke:#58a6ff,color:#c9d1d9
style SELECT fill:#161b22,stroke:#d29922,color:#c9d1d9
style EXTRACT fill:#161b22,stroke:#3fb950,color:#c9d1d9
style OUT fill:#0d1117,stroke:#8b949e,color:#c9d1d9

Loading

Deployment Topology

  graph TB
subgraph EDGE ["Edge (ESP32-S3 Mesh)"]
    E1["Node 1<br/><small>Kitchen</small>"]
    E2["Node 2<br/><small>Living room</small>"]
    E3["Node 3<br/><small>Bedroom</small>"]
end

subgraph SERVER ["Server (Rust · 132 MB Docker)"]
    SENSE["Sensing Server<br/><small>:3000 REST · :3001 WS · :5005 UDP</small>"]
    RVF["RVF Model<br/><small>Progressive 3-layer load</small>"]
    STORE["Time-Series Store<br/><small>In-memory ring buffer</small>"]
end

subgraph CLIENT ["Clients"]
    BROWSER["Browser<br/><small>Three.js UI · Gaussian splats</small>"]
    MOBILE["Mobile App<br/><small>WebSocket stream</small>"]
    DASH["Dashboard<br/><small>REST polling</small>"]
    IOT["Home Automation<br/><small>MQTT bridge</small>"]
end

E1 -->|"UDP :5005<br/>ADR-018 frames"| SENSE
E2 -->|"UDP :5005"| SENSE
E3 -->|"UDP :5005"| SENSE
SENSE <--> RVF
SENSE <--> STORE
SENSE -->|"WS :3001<br/>real-time JSON"| BROWSER & MOBILE
SENSE -->|"REST :3000<br/>on-demand"| DASH & IOT

style EDGE fill:#1a1a2e,stroke:#e94560,color:#eee
style SERVER fill:#16213e,stroke:#533483,color:#eee
style CLIENT fill:#0f3460,stroke:#0f3460,color:#eee

Loading

Component Crate / Module Description

Aggregator wifi-densepose-hardware ESP32 UDP listener, ADR-018 frame parser, I/Q → amplitude/phase bridge

Signal Processor wifi-densepose-signal SpotFi phase sanitization, Hampel filter, STFT spectrogram, Fresnel geometry, BVP

Subcarrier Selection ruvector-mincut + ruvector-attn-mincut Dynamic sensitive/insensitive partitioning, attention-gated noise suppression

Fresnel Solver ruvector-solver Sparse Neumann series O(sqrt(n)) for TX-body-RX distance estimation

Graph Transformer wifi-densepose-train COCO BodyGraph (17 kp, 16 edges), cross-attention CSI→pose, GCN message passing

SONA sona crate Micro-LoRA (rank-4) adaptation, EWC++ catastrophic forgetting prevention

Vital Signs wifi-densepose-signal FFT-based breathing (0.1-0.5 Hz) and heartbeat (0.8-2.0 Hz) extraction

REST API wifi-densepose-sensing-server Axum server: /api/v1/sensing, /health, /vital-signs, /bssid, /sona

WebSocket wifi-densepose-sensing-server Real-time pose, sensing, and vital sign streaming on :3001

Analytics wifi-densepose-mat Fall detection, activity recognition, START triage (WiFi-Mat disaster module)

Web UI ui/ Three.js scene, Gaussian splat visualization, signal dashboard

🖥️ CLI Usage

Rust Sensing Server — Primary CLI interface

Start with simulated data (no hardware)

./target/release/sensing-server --source simulate --ui-path ../../ui

Start with ESP32 CSI hardware

./target/release/sensing-server --source esp32 --udp-port 5005

Start with Windows WiFi RSSI

./target/release/sensing-server --source wifi

Run vital sign benchmark

./target/release/sensing-server --benchmark

Export RVF model package

./target/release/sensing-server --export-rvf model.rvf

Train a model

./target/release/sensing-server --train --dataset data/ --epochs 100

Load trained model with progressive loading

./target/release/sensing-server --model wifi-densepose-v1.rvf --progressive

Flag Description

--source Data source: auto, wifi, esp32, simulate

--http-port HTTP port for UI and REST API (default: 8080)

--ws-port WebSocket port (default: 8765)

--udp-port UDP port for ESP32 CSI frames (default: 5005)

--benchmark Run vital sign benchmark (1000 frames) and exit

--export-rvf Export RVF container package and exit

--load-rvf Load model config from RVF container

--save-rvf Save model state on shutdown

--model Load trained .rvf model for inference

--progressive Enable progressive loading (Layer A instant start)

--train Train a model and exit

--dataset Path to dataset directory (MM-Fi or Wi-Pose)

--epochs Training epochs (default: 100)

REST API & WebSocket — Endpoints reference REST API (Rust Sensing Server)

GET /api/v1/sensing # Latest sensing frame GET /api/v1/vital-signs # Breathing, heart rate, confidence GET /api/v1/bssid # Multi-BSSID registry GET /api/v1/model/layers # Progressive loading status GET /api/v1/model/sona/profiles # SONA profiles POST /api/v1/model/sona/activate # Activate SONA profile

WebSocket: ws://localhost:3001/ws/sensing (real-time sensing + vital signs)

Default ports (Docker): HTTP 3000, WS 3001. Binary defaults: HTTP 8080, WS 8765. Override with --http-port / --ws-port.

Hardware Support — Devices, cost, and guides

Hardware CSI Cost Guide

ESP32-S3 Native ~$8 Tutorial #34

Intel 5300 Firmware mod ~$15 Linux iwl-csi

Atheros AR9580 ath9k patch ~$20 Linux only

Any Windows WiFi RSSI only $0 Tutorial #36

Any macOS WiFi RSSI only (CoreWLAN) $0 ADR-025

Any Linux WiFi RSSI only (iw) $0 Requires iw + CAP_NET_ADMIN

Python Legacy CLI — v1 API server commands wifi-densepose start # Start API server wifi-densepose -c config.yaml start # Custom config wifi-densepose -v start # Verbose logging wifi-densepose status # Check status wifi-densepose stop # Stop server wifi-densepose config show # Show configuration wifi-densepose db init # Initialize database wifi-densepose tasks list # List background tasks

Documentation Links

WiFi-Mat User Guide | Domain Model

ADR-021 | ADR-022 | ADR-023

🧪 Testing

542+ tests across 7 suites — zero mocks, hardware-free simulation

Rust tests (primary — 542+ tests)

cd rust-port/wifi-densepose-rs cargo test --workspace

Sensing server tests (229 tests)

cargo test -p wifi-densepose-sensing-server

Vital sign benchmark

./target/release/sensing-server --benchmark

Python tests

python -m pytest v1/tests/ -v

Pipeline verification (no hardware needed)

./verify

Suite Tests What It Covers

sensing-server lib 147 Graph transformer, trainer, SONA, sparse inference, RVF

sensing-server bin 48 CLI integration, WebSocket, REST API

RVF integration 16 Container build, read, progressive load

Vital signs integration 18 FFT detection, breathing, heartbeat

wifi-densepose-signal 83 SOTA algorithms, Doppler, Fresnel

wifi-densepose-mat 139 Disaster response, triage, localization

wifi-densepose-wifiscan 91 8-stage RSSI pipeline

🚀 Deployment

Docker deployment — Production setup with docker-compose

Rust sensing server (132 MB)

docker pull ruvnet/wifi-densepose:latest docker run -p 3000:3000 -p 3001:3001 -p 5005:5005/udp ruvnet/wifi-densepose:latest

Python pipeline (569 MB)

docker pull ruvnet/wifi-densepose:python docker run -p 8765:8765 -p 8080:8080 ruvnet/wifi-densepose:python

Both via docker-compose

cd docker && docker compose up

Export RVF model

docker run --rm -v $(pwd):/out ruvnet/wifi-densepose:latest --export-rvf /out/model.rvf

Environment Variables

RUST_LOG=info # Logging level WIFI_INTERFACE=wlan0 # WiFi interface for RSSI POSE_CONFIDENCE_THRESHOLD=0.7 # Minimum confidence POSE_MAX_PERSONS=10 # Max tracked individuals

📊 Performance Metrics

Measured benchmarks — Rust sensing server, validated via cargo bench Rust Sensing Server

Metric Value

Vital sign detection 11,665 fps (86 µs/frame)

Full CSI pipeline 54,000 fps (18.47 µs/frame)

Motion detection 186 ns (~5,400x vs Python)

Docker image 132 MB

Memory usage ~100 MB

Test count 542+

Python vs Rust

Operation Python Rust Speedup

CSI Preprocessing ~5 ms 5.19 µs 1000x

Phase Sanitization ~3 ms 3.84 µs 780x

Feature Extraction ~8 ms 9.03 µs 890x

Motion Detection ~1 ms 186 ns 5400x

Full Pipeline ~15 ms 18.47 µs 810x

🤝 Contributing

Dev setup, code standards, PR process git clone https://github.com/ruvnet/RuView.git cd RuView

Rust development

cd rust-port/wifi-densepose-rs cargo build --release cargo test --workspace

Python development

python -m venv venv && source venv/bin/activate pip install -r requirements-dev.txt && pip install -e . pre-commit install

Fork the repository

Create a feature branch (git checkout -b feature/amazing-feature)

Commit your changes

Push and open a Pull Request

📄 Changelog

Release history v3.2.0 — 2026-03-03

Edge intelligence: 24 hot-loadable WASM modules for on-device CSI processing on ESP32-S3.

ADR-041 Edge Intelligence Modules — 24 no_std Rust modules compiled to wasm32-unknown-unknown, loaded via WASM3 on ESP32; 8 categories covering signal intelligence, adaptive learning, spatial reasoning, temporal analysis, AI security, quantum-inspired, autonomous systems, and exotic algorithms

Vendor Integration — Algorithms ported from midstream (DTW, attractors, Flash Attention, min-cut, optimal transport) and sublinear-time-solver (PageRank, HNSW, sparse recovery, spiking NN)

On-device gesture learning — User-teachable DTW gesture recognition with 3-rehearsal protocol and 16 template slots

Lifelong learning (EWC++) — Elastic Weight Consolidation prevents catastrophic forgetting when learning new tasks

AI security modules — FNV-1a replay detection, injection/jamming detection, 6D behavioral anomaly profiling with Mahalanobis scoring

Self-healing mesh — 8-node mesh with health tracking, degradation/recovery hysteresis, and coverage redistribution

Common utility library — vendor_common.rs shared across all 24 modules: CircularBuffer, EMA, WelfordStats, DTW, FixedPriorityQueue, vector math

243 tests passing — All modules include comprehensive inline tests; 0 failures

Security audit — 15 findings addressed (1 critical, 3 high, 6 medium, 5 low)

v3.1.0 — 2026-03-02

Multistatic sensing, persistent field model, and cross-viewpoint fusion — the biggest capability jump since v2.0.

Project RuvSense (ADR-029) — Multistatic mesh: TDM protocol, channel hopping (ch1/6/11), multi-band frame fusion, coherence gating, 17-keypoint Kalman tracker with re-ID; 10 new signal modules (5,300+ lines)

RuvSense Persistent Field Model (ADR-030) — 7 exotic sensing tiers: field normal modes (SVD), RF tomography, longitudinal drift detection, intention prediction, cross-room identity, gesture classification, adversarial detection

Project RuView (ADR-031) — Cross-viewpoint attention with geometric bias, Geometric Diversity Index, viewpoint fusion orchestrator; 5 new ruvector modules (2,200+ lines)

TDM Hardware Protocol — ESP32 sensing coordinator: sync beacons, slot scheduling, clock drift compensation (±10ppm), 20 Hz aggregate rate

Channel-Hopping Firmware — ESP32 firmware extended with hop table, timer-driven channel switching, NDP injection stub; NVS config for all TDM parameters; fully backward-compatible

DDD Domain Model — 6 bounded contexts, ubiquitous language, aggregate roots, domain events, full event bus specification

ruvector-crv 6-stage CRV signal-line integration (ADR-033) — Maps Coordinate Remote Viewing methodology to WiFi CSI: gestalt classification, sensory encoding, GNN topology, SNN coherence gating, differentiable search, MinCut partitioning; cross-session convergence for multi-room identity continuity

ADR-032 multistatic mesh security hardening — HMAC-SHA256 beacon auth, SipHash-2-4 frame integrity, NDP rate limiter, coherence gate timeout, bounded buffers, NVS credential zeroing, atomic firmware state

ADR-032a QUIC transport layer — midstreamer-quic TLS 1.3 AEAD for aggregator nodes, dual-mode security (ManualCrypto/QuicTransport), QUIC stream mapping, connection migration, congestion control

ADR-033 CRV signal-line sensing integration — Architecture decision record for the 6-stage CRV pipeline mapping to ruvector components

Temporal gesture matching — midstreamer-temporal-compare DTW/LCS/edit-distance gesture classification with quantized feature comparison

Attractor drift analysis — midstreamer-attractor Takens' theorem phase-space embedding with Lyapunov exponent regime detection (Stable/Periodic/Chaotic)

v0.3.0 published — All 15 workspace crates published to crates.io with updated dependencies

28,000+ lines of new Rust code across 26 modules with 400+ tests

Security hardened — Bounded buffers, NaN guards, no panics in public APIs, input validation at all boundaries

v3.0.0 — 2026-03-01

Major release: AETHER contrastive embedding model, AI signal processing backbone, cross-platform adapters, Docker Hub images, and comprehensive README overhaul.

Project AETHER (ADR-024) — Self-supervised contrastive learning for WiFi CSI fingerprinting, similarity search, and anomaly detection; 55 KB model fits on ESP32

AI Backbone (wifi-densepose-ruvector) — 7 RuVector integration points replacing hand-tuned thresholds with attention, graph algorithms, and smart compression; published to crates.io

Cross-platform RSSI adapters — macOS CoreWLAN and Linux iw Rust adapters with #[cfg(target_os)] gating (ADR-025)

Docker images published — ruvnet/wifi-densepose:latest (132 MB Rust) and :python (569 MB)

Project MERIDIAN (ADR-027) — Cross-environment domain generalization: gradient reversal, geometry-conditioned FiLM, virtual domain augmentation, contrastive test-time training; zero-shot room transfer

10-phase DensePose training pipeline (ADR-023/027) — Graph transformer, 6-term composite loss, SONA adaptation, RVF packaging, hardware normalization, domain-adversarial training

Vital sign detection (ADR-021) — FFT-based breathing (6-30 BPM) and heartbeat (40-120 BPM), 11,665 fps

WiFi scan domain layer (ADR-022/025) — 8-stage signal intelligence pipeline for Windows, macOS, and Linux

700+ Rust tests — All passing, zero mocks

v2.0.0 — 2026-02-28

Complete Rust sensing server, SOTA signal processing, WiFi-Mat disaster response, ESP32 hardware, RuVector integration, guided installer, and security hardening.

Rust sensing server — Axum REST API + WebSocket, 810x speedup over Python, 54K fps pipeline

RuVector integration — 11 vendored crates for HNSW, attention, GNN, temporal compression, min-cut, solver

6 SOTA signal algorithms (ADR-014) — SpotFi, Hampel, Fresnel, spectrogram, subcarrier selection, BVP

WiFi-Mat disaster response — START triage, 3D localization, priority alerts — 139 tests

ESP32 CSI hardware — Binary frame parsing, $54 starter kit, 20 Hz streaming

Guided installer — 7-step hardware detection, 8 install profiles

Three.js visualization — 3D body model, 17 joints, real-time WebSocket

Security hardening — 10 vulnerabilities fixed

📄 License

MIT License — see LICENSE for details.

📞 Support

GitHub Issues | Discussions | PyPI

WiFi DensePose — Privacy-preserving human pose estimation through WiFi signals.

Source: https://github.com/ruvnet/RuView
