WatchYourLAN
Lightweight network IP scanner with web GUI. Features:
Send notification when new host is found
Monitor hosts online/offline history
Keep a list of all hosts in the network
Send data to InfluxDB2 or Prometheus to make a Grafana dashboard
Important
Please, consider making a donation. Even $10 will make a difference to me.
More screenshots
Expand
Quick start
Expand Replace $YOURTIMEZONE with correct time zone and $YOURIFACE with network interface you want to scan. Network mode must be host. Set $DOCKERDATAPATH for container to save data:
docker run --name wyl
-e "IFACES=$YOURIFACE"
-e "TZ=$YOURTIMEZONE"
--network="host"
-v $DOCKERDATAPATH/wyl:/data/WatchYourLAN
aceberg/watchyourlan
Web GUI should be at http://localhost:8840
Auth
Expand WatchYourLAN does not have built-in auth option. But you can use it with SSO tools like Authelia, or my simple auth app ForAuth. Here is an example docker-compose-auth.yml.
⚠️ WARNING! Please, don't forget that WYL needs host network mode to work. So, WYL port will be exposed in this setup. You need to limit access to it with firewall or other measures.
Install on Linux
Expand All binary packages can be found in latest release. There are .deb, .rpm, .apk (Alpine Linux) and .tar.gz files.
Supported architectures: amd64, i386, arm_v5, arm_v6, arm_v7, arm64. Dependencies: arp-scan, tzdata.
For amd64 there is a deb repo available
Config
Expand Configuration can be done through config file, GUI or environment variables. Variable names is config_v2.yaml file are the same, but in lowcase.
Basic config
Variable Description Default
TZ Set your timezone for correct time
HOST Listen address 0.0.0.0
PORT Port for web GUI 8840
THEME Any theme name from https://bootswatch.com in lowcase or additional sand
COLOR Background color: light or dark dark
NODEPATH Path to local node modules
SHOUTRRR_URL WatchYourLAN uses Shoutrrr to send notifications. It is already integrated, just needs a correct URL. Examples for Discord, Email, Gotify, Matrix, Ntfy, Pushover, Slack, Telegram, Generic Webhook and etc are here
Scan settings
Variable Description Default
IFACES Interfaces to scan. Could be one or more, separated by space. See docs/VLAN_ARP_SCAN.md.
TIMEOUT Time between scans (seconds) 120
ARP_ARGS Arguments for arp-scan. Enable debug log level to see resulting command. (Example: -r 1). See docs/VLAN_ARP_SCAN.md.
ARP_STRS ARP_STRS_JOINED See docs/VLAN_ARP_SCAN.md.
LOG_LEVEL Log level: debug, info, warn or error info
TRIM_HIST Remove history after (hours) 48
HIST_IN_DB DEPRECATED since 2.1.3. Now History is always stored in DB. Use TRIM_HIST to reduce DB size
USE_DB Either sqlite or postgres sqlite
PG_CONNECT Address to connect to PostgreSQL. (Example: postgres://username:password@192.168.0.1:5432/dbname?sslmode=disable). Full list of URL parameters here
InfluxDB2 config
This config matches Grafana's config for InfluxDB data source
Variable Description Default Example
INFLUX_ENABLE Enable export to InfluxDB2 false true
INFLUX_SKIP_TLS Skip TLS Verify false true
INFLUX_ADDR Address:port of InfluxDB2 server
INFLUX_BUCKET InfluxDB2 bucket
test
INFLUX_ORG InfluxDB2 org
home
INFLUX_TOKEN Secret token, generated by InfluxDB2
Prometheus config
This config configures the Prometheus data source
Variable Description Default Example
PROMETHEUS_ENABLE Enable the Prometheus /metrics endpoint false true
Config file
Expand Config file name is config_v2.yaml. Example:
arp_args: "" color: dark host: 0.0.0.0 ifaces: enp4s0 influx_addr: "" influx_bucket: "" influx_enable: false influx_org: "" influx_skip_tls: false influx_token: "" log_level: info nodepath: "" pg_connect: "" port: "8840" prometheus_enable: false shoutrrr_url: "gotify://192.168.0.1:8083/AwQqpAae.rrl5Ob/?title=Unknown host detected&DisableTLS=yes" theme: sand timeout: 60 trim_hist: 48 use_db: sqlite
Options
Expand
Key Description Default
-d Path to config dir /data/WatchYourLAN
-n Path to node modules (see below)
Local network only
Expand By default, this app pulls themes, icons and fonts from the internet. But, in some cases, it may be useful to have an independent from global network setup. I created a separate image with all necessary modules and fonts. Run with Docker:
docker run --name node-bootstrap
-p 8850:8850
aceberg/node-bootstrap
docker run --name wyl
-e "IFACES=$YOURIFACE"
-e "TZ=$YOURTIMEZONE"
--network="host"
-v $DOCKERDATAPATH/wyl:/data/WatchYourLAN
aceberg/watchyourlan -n "http://$YOUR_IP:8850"
Or use docker-compose
API & Integrations
Expand API
Moved to docs/API.md
Integrations
ArchLinux (AUR) by gilcu3
Python API client by drwahl
Umbrel by Jasper
YunoHost
Thanks
Expand
All go packages listed in dependencies
Favicon and logo: Access point icons created by Freepik - Flaticon
Bootstrap
Themes: Free themes for Bootstrap
